Schneider NSX100H 3 Pole Molded Case Circuit Breaker 70 kA
Availability: In Stock

Schneider NSX100H 3 Pole Molded Case Circuit Breaker 70 kA

Product SKU: C10H3TM016
Rs.80,000

Safe Delivery

Quick & safe nation wide delivery

Easy Return

Hassle free return within 7 days

100% Original Product

Only genuine products, no compromises.

 WhatsApp Inquiry

Specifications

Range ComPacT new generation
device short name NSXIOOH
Product or component type Circuit breaker
Device application Distribution
Poles description 3P
Protected poles description 3D
[In] rated current 16 A at 40 oc
[Uel rated operational voltage 690 V AC 50/60 Hz
Network type AC
Network frequency 50/60 Hz
Suitability for isolation Yes conforming to EN/IEC 60947-2
utilisation category Category A
[Icu] rated ultimate short-circuit breaking capacity 70 kA
Performance level H 70 kA415VAC
Trip unit name TM-D
Trip unit technology Thermal-magnetic
Trip unit protection functions LI
control type Toggle
Circuit breaker mounting mode Fixed
[UiJ rated insulation voltage 800 V AC 50/60 Hz
[Uimp] rated impulse withstand voltage 8 kV
Mechanical durability 50000 cycles
Electrical durability 50000 cycles at 440 V In/2 / 30000 cycles at 440 V In / 20000 cycles at 690 V In/2 / 10000 cycles at 690 V In
Net weight 2.05 kg

Key Features

High power motor
Higher work efficiency
Product Details Reviews Shipping & Returns

Schneider NSX100H 3 Pole Molded Case Circuit Breaker 70 kA




This ComPacT NSX100H is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 70kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 16A, 25A, 40A, 63A, 80A, 100 rating thermal-magnetic trip unit (TMD). TMD trip unit provides adjustable thermal overload protection and a fixed magnetic protection. This 3-pole version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. ComPacT NSX100H is part of Schneider Electric EcoStruxure Power architecture.
