Range of product
|
easypact
|
|
product or component type
|
circuit breaker
|
|
circuit breaker name
|
easypact ezc250h
|
|
device application
|
distribution
|
This is a 125A, 150A, 200A, 225A, 250A circuit breaker for EasyPact EZC250H. This product can work below rated operational voltage(Ue) 550VAC at 50/60Hz or 250VDC network. The ultimate breaking capacity(Icu) is shown differently, depending on the condition of the network, Ics=50%Icu if needed to match. This version of the product is designed with 3 pole frame with detection on 3 poles, equipped TMD trip unit for thermal-magnetic protection. It is in compliance with standard IEC60947, CE certification, and some independent labs (KEMA, ASEFA, TUV) or third-party Tilva. This device is certified for operation in a pollution degree III environment as defined by IEC60947 and passes the test of extreme atmospheric conditions. The device can be mounted vertically or horizontally in a metal enclosure, and against safety risk by pad...
