Schneider LC1-G185 TeSys G Contactor-3P High power contactor
Availability: In Stock

Schneider LC1-G185 TeSys G Contactor-3P High power contactor

Product SKU: LC1G185KUEN
Rs.210,000

Safe Delivery

Quick & safe nation wide delivery

1 Year Warranty

Reliable 1-year protection

Easy Return

Hassle free return within 7 days

100% Original Product

Only genuine products, no compromises.

 WhatsApp Inquiry

Offer & Coupon

Get Flat Rs 300 Off on HIMEL Min Cart Value Rs 4500

Specifications

Range of Product TeSys F
Component Type Contactor
Device Short Name LC1F
Contactor Application Resistive load / Motor control
Poles description 3P
Thermal Current Ampere 275
Capacity 100 / 134 KW (HP)
Rated Operational Voltage [Ue] <= 460 V DC / <= 690 V AC 50/60 Hz
Rated Operational Current [Ie] 275 A (at <40 å¡C) at <= 440 V AC-1 / 185 A (at <55 å¡C) at <= 440 V AC-3
Control Circuit Voltage [Uc] 220 V AC 40...400 Hz
Net weight 4.65 kg
Compatibility code LC1F
Pole Contact Composition 3 NO
Conventional Free Air Thermal Current [Ith] 275 A (at 40 å¡C)
Rated Breaking Capacity 1480 A conforming to IEC 60947-4-1
Average Impedance 0.33 mOhm - Ith 275 A 50 Hz
Overvoltage category III
Mechanical Durability 10 Mcycles
Control Circuit Type AC at 40...400 Hz
Heat dissipation 8‰Û?9.8 W
Operating time 35 ms closing (at Uc) / 130 ms opening (at Uc)
Mounting Support Plate
Operating altitude 3000 m without derating

Key Features

High power motor
Higher work efficiency
Product Details Reviews Shipping & Returns

Schneider LC1-G185 TeSys G Contactor-3P High power contactor


TeSys Giga high power contactor, 3 poles (3 NO) for category AC-3 applications up to 185A 110kW@440V. It provides a 100-250V AC/DC wide band low consumption electronic coil and embedded highly reliability 1NO+1NC auxiliary contact block (17V 1mA). Designed for demanding applications with maximum operating rates up to 600 cycles per hour and environments until 60å¡C. It procures high reliability and durability with 5 Mcycles mechanical durability. Local Contact Wear Diagnosis (CWD) as standard function, continuous monitoring with healthy and alarm indicators. It is possibility to replace switching module (main contacts), enhancement contactor life. Contactor can be fixed in all quadrants, maintenance without removing cables/busbars, and OLR could be directly mounted below contactor. To be used with power connection by bolted connection and control connections by spring terminals, accessible from front for easy and quick replacement. It provides IP2x protection in Front face with shrouds conforming to IEC 60529 and VDE 0106. It can cover -25å¡C to 60å¡C operation ambient air temperature and directly mounted on plate, No derating up to 3000m altitude. The dimension is 255mm x 108mm x 175mm (H x W x D), compact size enables panel space savings. Multi standards certified(CE,CB,CCC,cULus,EAC,KC,RCM,Marine) and Green Premium compliant (RoHs/Reach). Unique QR code provides quick access to complete product data.
