Availability:
In Stock
Schneider CVS400F 3 Pole Molded Case Circuit Breaker
Product SKU:
LV540305
Rs.150,000
Safe Delivery
Quick & safe nation wide delivery
Easy Return
Hassle free return within 7 days
100% Original Product
Only genuine products, no compromises.
Couldn't load pickup availability
Specifications
Range
EasyPact
Product name
EasyPact CVS
Device short name
CVS400F
Product or component type
Circuit breaker
Device application
Distribution
Poles description
3P
Weight
4.7 kg
Protected poles description
3D
Earth leakage protection (Vigi add on)
Without
Rated current [In]
320 A at 40 °C
Network type
AC
Utilisation category
Category A
Breaking capacity [Icu]
36 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
Trip unit name
TM-D
Trip unit technology
Thermal-magnetic
Trip unit rating
320 A at 40 °C
Protection type
Overload protection (thermal) / Short-circuit protection (magnetic)
[Uimp] rated impulse withstand voltage
8 kV conforming to EN/IEC 60947-2
Network frequency
50/60 Hz
Breaking capacity code
F
Mechanical durability
15000 cycles
Electrical durability
6000 cycles 415 V In conforming to IEC 60947-2
control type
Toggle
Thermal protection adjustment range
224…320 A
Long-time pick-up adjustment type Ir
Adjustable
long-time pick-up adjustment range
0.7...1 x In
Long-time delay adjustment type
Fixed
instantaneous pick-up adjustment type Ii
Adjustable
instantaneous pick-up adjustment range
5...10 x In
Contact position indicator
Yes
Mounting mode
Fixed
mounting support
Backplate
Upside connection
Front
downside connection
Front
Standards
EN 60947-2 / IEC 60947-2
Electrical shock protection class
Class II
Pollution degree
3 conforming to IEC 60664-1
IP degree of protection
IP40
Ambient air temperature for operation
-25…70 °C
Ambient air temperature for storage
-50…85 °C
Key Features
High power motor
Higher work efficiency
Product Details
Reviews
Shipping & Returns
User Manual
Schneider CVS400F 3 Pole Molded Case Circuit Breaker
EasyPact CVS400F is a 3-pole 3d fixed circuit breaker with a high level of performance and cost-saving functionality. It is an optimal choice for small and medium-sized building protection applications. The breaking capacity (Icu) is 36kA rms at 415VAC 50/60Hz. The operational voltage is 440VAC 50/60Hz. This product embeds a 320A, 400A rating thermal-magnetic trip unit (TMD). TMD trip unit provides adjustable thermal overload protection and fixed magnetic protection. This 3-pole version (140mm x 255mm x 110mm) comes with a variety of optional functions and accessories. EasyPact CVS400F is compliant with international standards (IEC 60947, CCC, EAC). It can be installed in class II insulation switchboards as it is a class II front-face device (IEC 60664-1).
Looking to purchase Schneider CVS400F 3 Pole Molded Case Circuit Breaker in bulk?
- Purchase Item in Bulk Quantity
- Get At Best Price For Your Business
Bulk Enquiry
No reviews yet. Be the first to review this product.
Shipping
We ship across Pakistan. Standard delivery takes 3–7 business days.
Returns
Easy 7-day return policy. Product must be unused and in original packaging.
Download User Manual
Click here to download PDF (schneider-cvs400f-3p-mccb-breaker-320a.pdf)
Download User Manual
Click here to download PDF (schneider-cvs400f-3p-mccb-breaker-400a.pdf)
