Schneider LC1G800 TeSys F Contactor 4P (3 NO) AC-3 800 A 220 V AC Coil
Product SKU:
LC1G8004KUEN
Rs.1,090,000
Safe Delivery
Quick & safe nation wide delivery
Easy Return
Hassle free return within 7 days
100% Original Product
Only genuine products, no compromises.
Couldn't load pickup availability
Specifications
Range
TeSys
Range of product
TeSys Giga
Product or component type
Contactor
Device short name
LC1G
Contactor application
Power switching
Utilisation category
AC-3
AC-3e
AC-1
AC-5a
AC-5b
AC-6a
AC-6b
DC-1
DC-3
DC-5
Poles description
4P
[Ue] rated operational voltage
<= 1000 V AC 50/60 Hz
<= 460 V DC
[Ie] rated operational current
800 A (at <60 °C) at <= 440 V AC-3
1050 A (at <40 °C) at <= 1000 V AC-1
[Uc] control circuit voltage
100...250 V AC 50/60 Hz
100...250 V DC
Control circuit voltage limits
Operational: 0.8 Uc Min...1.1 Uc Max (at <60 °C)
Drop-out: 0.1 Uc Max...0.45 Uc Min (at <60 °C)
[Uimp] rated impulse withstand voltage
8 kV
Overvoltage category
III
[Ith] conventional free air thermal current
1050 A (at 40 °C)
Rated breaking capacity
5870 A at 440 V
[Icw] rated short-time withstand current
5.5 kA - 10 s
4.6 kA - 30 s
3.6 kA - 1 min
2.6 kA - 3 min
1.7 kA - 10 min
Associated fuse rating
800 A aM at <= 440 V for motor
630 A aM at <= 690 V for motor
1250 A gG at <= 690 V
Average impedance
0.000065 Ohm
[Ui] rated insulation voltage
1000 V
Power dissipation per pole
70 W AC-1 - Ith 1050 A
42 W AC-3 - Ith 800 A
Compatibility code
LC1G
Pole contact composition
4 NO
Auxiliary contact composition
1 NO + 1 NC
Irms rated making capacity
7640 A at 440 V
Coil technology
Built-in bidirectional peak limiting
Safety reliability level: B10d = 100000 cycles contactor with nominal load conforming to EN/ISO 13849-1
B10d = 1800000 cycles contactor with mechanical load conforming to EN/ISO 13849-1
Mechanical durability
5 Mcycles
inrush power in W (DC)
680 W
hold-in power consumption in VA (50/60 Hz, AC)
15.0 VA
hold-in power consumption in W (DC)
9.5 W
Operating time
40...70 ms closing
15...50 ms opening
Maximum operating rate
600 cyc/h AC-3
600 cyc/h AC-3e
300 cyc/h AC-1
Connections - terminals
Power circuit: bar 2 - busbar cross section: 52 x 20 mm
Power circuit: lugs-ring terminals 1 185 mm²
Power circuit: bolted connection
Control circuit: push-in 1 0.2…2.5 mm² - cable stiffness: solid stranded without cable end
Control circuit: push-in 1 0.25…2.5 mm² - cable stiffness: flexible with cable end
Control circuit: push-in 2 0.5…1.0 mm² with cable end
Control circuit: push-in 0.75…2.5 mm² - cable stiffness: solid stranded without cable end
Control circuit: push-in 0.75…2.5 mm² - cable stiffness: flexible with cable end
ightening torque
58 N.m
Height
284 mm
Width
281 mm
Net weight
18 kg
Key Features
High power motor
Higher work efficiency
Product Details
Reviews
Shipping & Returns
Schneider LC1G800 TeSys F Contactor 4P (3 NO) AC-3 800 A 220 V AC Coil
The Schneider LC1G800 TeSys F Contactor is a high-performance solution for power switching and motor control applications. Designed for reliability, it supports AC-3 utilization up to 800A and operates on a 220V AC coil, making it ideal for industrial settings.
