Schneider CVS100B 3 Pole Molded Case Circuit Breaker, 25 kA Price in Pakistan
  • Schneider CVS100B 3 Pole Molded Case Circuit Breaker, 25 kA Price in Pakistan
Schneider CVS100B 3 Pole Molded Case Circuit Breaker 25 kA
Availability: Out of stock

Schneider CVS100B 3 Pole Molded Case Circuit Breaker 25 kA

Product SKU: LV510300
Rs.21,000

Safe Delivery

Quick & safe nation wide delivery

Easy Return

Hassle free return within 7 days

100% Original Product

Only genuine products, no compromises.

 WhatsApp Inquiry

Specifications

Range EasyPact Product name: EasyPact CVS Device short name: CVS100B Product or component type: Circuit breaker Device application: Distribution Poles description: 3P Protected poles description: 3D Net weight: 1.8 kg Earth leakage protection (Vigi add-on): Without Rated current [In]: 16 A at 40 °C Network type: AC Network frequency: 50/60 Hz
utilization category Category A
Breaking capacity [Icu] 25 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
Trip unit name TM-D
Trip unit technology Thermal-magnetic
Trip unit rating 16 A, 25A, 32A, 40A, 50A, 63A, 80A, 100A at 40 °C
Protection type Short-circuit protection (magnetic) / Overload protection (thermal)
Rated impulse withstand voltage [Uimp] 8 kV conforming to EN/IEC 60947-2
Breaking capacity code B
Mechanical durability 30000 cycles
Electrical durability 12000 cycles 415 V In conforming to IEC 60947-2
control type Toggle
Thermal protection adjustment range 11.2…16 A
Long time pick-up adjustment type Ir Adjustable
long time pick-up adjustment range 0.7...1 x In
Long time delay adjustment type Fixed
instantaneous pick-up adjustment type Ii Fixed
instantaneous pick-up adjustment range 190 A
Contact position indicator Yes
Mounting mode Fixed
mounting support Backplate
Upside connection Front
downside connection Front
Standards IEC 60947-2 / EN 60947-2
product certifications IEC / GOST
Electrical shock protection class Class II
Pollution degree 3 conforming to IEC 60664-1
IP degree of protection IP40
Ambient air temperature for operation -25…70 °C
Ambient air temperature for storage -50…85 °C

Key Features

High power motor
Higher work efficiency
Product Details Reviews Shipping & Returns

Schneider CVS100B 3 Pole Molded Case Circuit Breaker 25 kA

EasyPact CVS100B is a 3-pole 3d fixed circuit breaker with a high level of performance and cost-saving functionality. It is an optimal choice for small and medium-sized building protection applications. The breaking capacity (Icu) is 25kA rms at 415VAC 50/60Hz. The operational voltage is 440VAC 50/60Hz. This product embeds a 16A, 25A, 32A, 40A, 50A, 63A, 80A, 100A rating thermal-magnetic trip unit (TMD). TMD trip unit provides adjustable thermal overload protection and fixed magnetic protection. This 3-pole version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. EasyPact CVS100B is compliant with international standards (IEC 60947, CCC, EAC). It can be installed in class II insulation switchboards as it is a class II front-face device (IEC 60664-1).

Schneider CVS100B 3 Pole Molded Case Circuit Breaker, 25 kA Price in Pakistan
Schneider CVS100B 3 Pole Molded Case Circuit Breaker 25 kA
Looking to purchase Schneider CVS100B 3 Pole Molded Case Circuit Breaker 25 kA in bulk?
  • Purchase Item in Bulk Quantity
  • Get At Best Price For Your Business
No reviews yet. Be the first to review this product.

Shipping

We ship across Pakistan. Standard delivery takes 3–7 business days.

Returns

Easy 7-day return policy. Product must be unused and in original packaging.
