  • Schneider CVS160F 4P MCCB Breaker 160A Price in Pakistan
Schneider CVS160F 4 Pole Molded Case Circuit Breaker 36 kA
Availability: In Stock

Schneider CVS160F 4 Pole Molded Case Circuit Breaker 36 kA

Product SKU: LV516352
Rs.70,000

Safe Delivery

Quick & safe nation wide delivery

Easy Return

Hassle free return within 7 days

100% Original Product

Only genuine products, no compromises.

 WhatsApp Inquiry

Specifications

Range EasyPact
Product name EasyPact CVS
device short name CVS160F
Product or component type Circuit breaker
Device application Distribution
Poles description 4P
Net weight 2.3 kg
Protected poles description 4D
Earth leakage protection (Vigi add on) Without
Rated current [In] 125, 160a A at 40 °C
Network type AC
utilisation category Category A Breaking capacity [Icu]: 36 kA
Trip unit name TM-D
Trip unit technology Thermal-magnetic
Protection type Short-circuit protection (magnetic) / Overload protection (thermal)
Rated impulse withstand voltage [Uimp] 8 kV conforming to EN/IEC 60947-2
Network frequency 50/60 Hz
Breaking capacity code F
Rated service breaking capacity [Ics] 36000 A
Mechanical durability 25000 cycles
Electrical durability 12000 cycles 415 V In conforming to IEC 60947-2
control type Toggle
Thermal protection adjustment range 87.5…125 A
Long time pick-up adjustment type Ir Adjustable
long time pick-up adjustment range 0.7...1 x In
Long time delay adjustment type Fixed
instantaneous pick-up adjustment type Ii Fixed
instantaneous pick-up adjustment range 1250 A
Contact position indicator Yes
Mounting mode Fixed
mounting support Backplate
Upside connection Front
downside connection Front
Standards EN 60947-2 / IEC 60947-2
Electrical shock protection class Class II
Pollution degree 3 conforming to IEC 60664-1
IP degree of protection IP40
Ambient air temperature for operation -25…70 °C Ambient air temperature for storage: -50…85 °C

Key Features

High power motor
Higher work efficiency
Product Details Reviews Shipping & Returns

Schneider CVS160F 4 Pole Molded Case Circuit Breaker 36 kA

EasyPact CVS160F is a 4-pole 4D fixed circuit breaker with a high level of performance and cost-saving functionality. It is an optimal choice for small and medium-sized building protection applications. The breaking capacity (Icu) is 36kA rms at 415VAC 50/60Hz. The operational voltage is 440VAC 50/60Hz. This product embeds a 125A, 160A rating thermal-magnetic trip unit (TMD). TMD trip unit provides adjustable thermal overload protection and fixed magnetic protection. This 4-pole version (140mm x 161mm x 86mm) comes with a variety of optional functions and accessories. EasyPact CVS160F is compliant with international standards (IEC 60947, CCC, EAC). It can be installed in class II insulation switchboards as it is a class II front-face device (IEC 60664-1).
