Schneider NSX160F 4 Pole Molded Case Circuit Breaker 36 kA
Availability: In Stock

Schneider NSX160F 4 Pole Molded Case Circuit Breaker 36 kA

Product SKU: C16F6TM125
Rs.90,000

Safe Delivery

Quick & safe nation wide delivery

Easy Return

Hassle free return within 7 days

100% Original Product

Only genuine products, no compromises.

 WhatsApp Inquiry

Specifications

Range CornPacT new generation
Product name ComPacT NSX new generation
Product or component type Circuit breaker
Device application Distribution
Poles description 4P
Protected poles description 3D
Neutral position Left
[In] rated current 125 A at 40 oc
[Uel rated operational voltage 690 V AC 50/60 Hz
Network type AC
Network frequency 50/60 Hz
Suitability for isolation Yes conforming to EN/IEC 60947-2
utilisation category Category A
[Icu] rated ultimate short-circuit breaking capacity 36 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
Performance level F36kA415VAC
Trip unit name TM-D
Trip unit technology Thermal-magnetic
Trip unit protection functions LI
control type Toggle
Circuit breaker mounting mode Fixed
[Ui] rated insulation voltage 800 V AC 50/60 Hz
[UimpJ rated impulse withstand voltage 8 KV
Mechanical durability 40000 cycles
Electrical durability 40000 cycles at 440 V In/2 / 20000 cycles at 440 V In / 15000 cycles at 690 V In/2 / 7500 cycles at 690 V In
Net weight 2.6 kg
Standards EN/IEC 60947
product certifications ccc, EAC, Marine
Overvoltage category Class II
Electrical shock protection class Class II
Pollution degree 3 conforming to IEC 60664-1
IP degree Of protection IP40 conforming to IEC 60529
1K degree of protection IK07 conforming to IEC 62262
ambient air temperature for operation - 25...70 c
Ambient air temperature for storage -50...85 c
Relative humidity 0...95 0/0
Operating altitude 0.-.2000 m without derating / 2000 m...5000 m with derating

Key Features

High power motor
Higher work efficiency
Product Details Reviews Shipping & Returns

Schneider NSX160F 4 Pole Molded Case Circuit Breaker 36 kA


This ComPacT NSX160F is a complete 4P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 36kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 125A, 160A rating thermal-magnetic trip unit (TMD). TMD trip unit provides adjustable thermal overload protection and fixed magnetic protection. This 4-pole version (140mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC, and marine specifications. ComPacT NSX160F is part of Schneider Electric EcoStruxure Power architecture.
