Schneider MasterPact NW40H1 3 Pole 4000A Air Circuit Breaker
Product SKU:
48092
Rs.2,750,000
Safe Delivery
Quick & safe nation wide delivery
Easy Return
Hassle free return within 7 days
100% Original Product
Only genuine products, no compromises.
Couldn't load pickup availability
Specifications
Range
MasterPacT
Product name
MasterPact NW
Net weight
50 kg
circuit breaker name
MasterPact NW40H 1
Product or component type
Circuit breaker
Device application
Power distribution protection
Poles description
3P
Control unit
Without control unit
Rated current [In]
4000 A at 40 oc
Performance type
HI 65 kA440 V AC
rated operational voltage [Uel
690 V AC 50/60 Hz
Suitability for isolation
Yes conforming to EN/IEC 60947-2
Selectivity category
Category B
control type
Push-button
Mounting mode
Fixed
Rated ultimate short-circuit breaking capacity [Icu]
65KA
Rated short-time withstand current [Icw]
65 kA 1 s / 65 kA 3 s
Sensor rating
2000 A / 4000 A
Rated insulation voltage [Ui]
1000 V AC 50/60 Hz
Rated impulse withstand voltage [Uimp]
12 kV
Power dissipation in W
650 W
Maximum breaking time
25 ms
maximum closing response time
70 ms
mounting support
Backplate Rails
Upside connection
Rear
downside connection
Rear
Mechanical durability
10000 cycles without maintenance / 20000 cycles with maintenance
IP degree of protection
IP30 conforming to IEC 60529
Pollution degree
4 conforming to IEC 60664-1
Ambient air temperature for operation
-25…70 °C
Ambient air temperature for storage
-40…85 °C
Operating altitude
0...2000 m without derating / 2000 m...5000 m with derating
Key Features
High power motor
Higher work efficiency
Product Details
Reviews
Shipping & Returns
Schneider MasterPact NW40H1 3 Pole 4000A Air Circuit Breaker
The Circuit Breaker Frame, MasterPact NW40H1, is a robust and high-performance electrical protection device designed for industrial applications. With a range of current ratings including 4000A, and a short-circuit breaking capacity of 65kA at 440VAC 50/60Hz (Icu), this three-pole fixed frame ensures reliable and efficient power distribution. Notably, it operates without a control unit, making it a simplified and essential component for circuit protection in demanding environments.
