Schneider LC1-G3304 TeSys Giga 4 pole (4NO) AC-1 440V 550A AC/DC Coil
Availability: In Stock

Schneider LC1-G3304 TeSys Giga 4 pole (4NO) AC-1 440V 550A AC/DC Coil

Product SKU: LC1–G3304KUEN
Rs.850,000

Safe Delivery

Quick & safe nation wide delivery

Easy Return

Hassle free return within 7 days

100% Original Product

Only genuine products, no compromises.

 WhatsApp Inquiry

Specifications

Range TeSys
Range of product TeSys Giga
Product or component type Contactor
Device short name LC1G
Contactor application Power switching
Utilisation category AC-3 : AC-3e : AC-1 : AC-5a : AC-5b : AC-6a : AC-6b : DC-1 : DC-3 : DC-5
Poles description 4P
[Ue] rated operational voltage <= 1000 V AC 50/60 Hz : <= 460 V DC
[Ie] rated operational current 400 A (at <60 °C) at <= 440 V AC-3 : 550 A (at <40 °C) at <= 1000 V AC-1
[Uc] control circuit voltage 100...250 V AC 50/60 Hz : 100...250 V DC
Control circuit voltage limits Operational: 0.8 Uc Min...1.1 Uc Max (at <60 °C) : Drop-out: 0.1 Uc Max...0.45 Uc Min (at <60 °C)
[Uimp] rated impulse withstand voltage 8 kV
Overvoltage category III
[Ith] conventional free air thermal current 550 A (at 40 °C)
Rated breaking capacity 3480 A at 440 V
[Icw] rated short-time withstand current 3.6 kA - 10 s : 2.4 kA - 30 s : 1.7 kA - 1 min : 1.2 kA - 3 min : 1.0 kA - 10 min
Associated fuse rating 500 A aM at <= 440 V for motor : 315 A aM at <= 690 V for motor : 630 A gG at <= 690 V
Average impedance 0.0001 Ohm
[Ui] rated insulation voltage 1000 V
Power dissipation per pole 30 W AC-1 - Ith 550 A : 16 W AC-3 - Ith 400 A
Compatibility code LC1G
Pole contact composition 4 NO
Auxiliary contact composition 1 NO + 1 NC
Irms rated making capacity 5090 A at 440 V
Coil technology Built-in bidirectional peak limiting
Safety reliability level B10d = 400000 cycles contactor with nominal load conforming to EN/ISO 13849-1 : B10d = 3000000 cycles contactor with mechanical load conforming to EN/ISO 13849-1
Mechanical durability 8 Mcycles
Inrush power in VA (50/60 Hz, AC) 750 VA
Inrush power in W (DC) 660 W
Hold-in power consumption in VA (50/60 Hz, AC) 15.5 VA
Hold-in power consumption in W (DC) 9.3 W
Operating time 40...70 ms closing : 15...50 ms opening
Maximum operating rate 600 cyc/h AC-3 : 600 cyc/h AC-3e : 300 cyc/h AC-1
Connections - terminals Power circuit: bar 2 - busbar
cross section 32 x 10 mm : Power circuit: lugs-ring terminals 1 185 mm² : Control circuit: push-in 1 0.2…2.5 mm² - cable stiffness: solid stranded without cable end : Control circuit: push-in 1 0.25…2.5 mm² - cable stiffness: flexible with cable end : Control circuit: push-in 2 0.5…1.0 mm² with cable end : Control circuit: push-in 0.75…2.5 mm² - cable stiffness: solid stranded without cable end : Control circuit: push-in 0.75…2.5 mm² - cable stiffness: flexible with cable end
Connection pitch 45 mm
Mounting support Plate
Standards EN/IEC 60947-4-1 : EN/IEC 60947-5-1 : UL 60947-4-1 : CSA C22.2 No 60947-4-1 : JIS C8201-4-1 : JIS C8201-5-1 : UL 60335-1 : UL 60335-2-40:Annex JJ
Product certifications CB Scheme : CCC : cULus : EAC : CE : UKCA : EU-RO-MR by DNV-GL
Tightening torque 35 N.m
Height 225 mm Width : 185 mm Depth : 226 mm Net weight : 8.3 kg

Key Features

High power motor
Higher work efficiency
Product Details Reviews Shipping & Returns User Manual

Schneider LC1-G3304 TeSys Giga 4 pole (4NO) AC-1 440V 550A AC/DC Coil


TeSys Giga high power contactor, 4 poles (4 NO) for category AC-1 applications up to 550A @440V. Equipped with 100-250 V AC/DC wide band low consumption electronic coil and embedded highly reliable 1NO+1NC auxiliary contact block (17V 1mA). Designed for demanding applications with maximum operating rates up to 300 cycles per hour and environments up to 60°C. It’s built with high reliability delivering mechanical durability up to 8 million cycles. Contact Wear Diagnosis (CWD) is a standard function, which continuously monitors and provide feedback through healthy and alarm conditions by an LED indicator. It is possible to replace switching module (main contacts), control module enhancing contactor life with simple maintenance activities. Front accessible main power connections are with bolted connection and control connections by push-in terminals for easy and quick assembly. It provides IP2x protection from front face with optional terminal shrouds conforming to IEC 60529 and VDE 0106. It can cover -25°C to 60°C operation ambient air temperature and directly mounted on plate, with no derating up to 3000m altitude. Contactor can be installed in three quadrants of vertical plane, and OLR could be directly mounted below contactor. The dimensions are 225 mm x 185 mm x 226 mm (H x W x D), compact size enables panel space savings. Multi standards certified (CB, CCC, cULcs, CE, UKCA marking). Unique QR code provides quick access to complete product data.
