Schneider LC1D115 TeSys D Contactor Price in Pakistan
  • Schneider LC1D115 TeSys D Contactor Price in Pakistan
Schneider LC1D115 TeSys D Contactor 3P (3 NO) AC-3 115 A 220 V AC Coil
Availability: In Stock

Schneider LC1D115 TeSys D Contactor 3P (3 NO) AC-3 115 A 220 V AC Coil

Product SKU: LC1D115M7
Rs.66,000

Safe Delivery

Quick & safe nation wide delivery

Easy Return

Hassle free return within 7 days

100% Original Product

Only genuine products, no compromises.

 WhatsApp Inquiry

Specifications

Range of Product TeSys Deca
Component Type Contactor
Device Short Name LC1D
Contactor Application Motor control
Poles description 3P
Thermal Current Ampere 200
Capacity 59 / 77 KW (HP)
Rated Operational Voltage [Ue] Power circuit; <= 1000 V AC 25...400 Hz / Power circuit; <= 300 V DC
Rated Operational Current [Ie] 200 A
Control Circuit Voltage [Uc] 220 V AC 50/60 Hz
Net weight 2.5 kg
Compatibility code LC1D
Pole Contact Composition 3 NO
Contact Compatibility M13
Protective cover With
Conventional Free Air Thermal Current [Ith] 200 A (at 60 °C) for power circuit
Rated Breaking Capacity 1100 A at 440 V for power circuit conforming to IEC 60947
Average Impedance 0.6 mOhm - Ith 200 A 50 Hz for power circuit
Overvoltage category III
Pollution degree 3
Mechanical Durability 8 Mcycles
Control Circuit Type AC at 50/60 Hz standard
Heat dissipation 3…8 W at 50/60 Hz
Operating time 6...20 ms opening / 20...50 ms closing
Auxiliary contact composition 1 NO + 1 NC
Signalling circuit frequency 25...400 Hz
Minimum switching voltage 17 V for signalling circuit
Minimum switching current 5 mA for signalling circuit
Insulation resistance > 10 MOhm for signalling circuit
Mounting Support Plate Rail
Operating altitude 0...3000 m
Fire resistance 850 °C conforming to IEC 60695-2-1
Flame retardance V1 conforming to UL 94

Key Features

High power motor
Higher work efficiency
Product Details Reviews Shipping & Returns

Schneider LC1D115 TeSys D Contactor 3P (3 NO) AC-3 115 A 220 V AC Coil

TeSys Deca contactor, 3 poles (3NO), for motor control applications up to 115A/1000V AC-3 (55kW@400V). It provides a 220V 50/60Hz AC coil with transient suppressor module, 1NO+1NC built-in auxiliary contacts (NC mirrror certified), power connection by screw connectors 2 inputs, control connection by screw clamp terminals. For operating rates until 2400 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (120mm width), mounting on 2 DIN-rails or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).

Schneider LC1D115 TeSys D Contactor Price in Pakistan
Schneider LC1D115 TeSys D Contactor 3P (3 NO) AC-3 115 A 220 V AC Coil
Looking to purchase Schneider LC1D115 TeSys D Contactor 3P (3 NO) AC-3 115 A 220 V AC Coil in bulk?
  • Purchase Item in Bulk Quantity
  • Get At Best Price For Your Business
No reviews yet. Be the first to review this product.

Shipping

We ship across Pakistan. Standard delivery takes 3–7 business days.

Returns

Easy 7-day return policy. Product must be unused and in original packaging.
