Schneider LC1F1504 TeSys D Contactor 4P (4 NO) AC-1 250A 440 V AC without coil

Availability: Out of stock

Schneider LC1F1504 TeSys D Contactor 4P (4 NO) AC-1 250A 440 V AC without coil

Name: Schneider LC1F1504 TeSys D Contactor 4P (4 NO) AC-1 250A 440 V AC without coil
Brand: Schneider Electric
Price: 140000.0 PKR
Availability: OutOfStock

Product SKU: LC1F1504

Rs.140,000

Safe Delivery

Quick & safe nation wide delivery

Easy Return

Hassle free return within 7 days

100% Original Product

Only genuine products, no compromises.

Specifications

Range of Product TeSys

Device Short Name LC1F

Contactor Application Resistive load

Poles description 4P

Net weight 3.83 kg

Thermal Current Ampere 150A

Capacity 80 / 105 KW (HP)

Rated Operational Voltage [Ue] <= 690 V AC 50/60 Hz <= 460 V DC

Rated Operational Current [Ie] 250 A (at <40 °C) at <= 440 V AC-1

Control Circuit Voltage [Uc] 24...575 V AC 40...400 Hz with LX1/LX9 coil / 24...460 V DC with LX4 coil / 100...250 V AC 50/60 Hz with LXE coil / 100...380 V DC with LXE coil

Compatibility code LC1F

Pole Contact Composition 4 NO

Conventional Free Air Thermal Current [Ith] 250 A (at 40 °C)

Rated Breaking Capacity 1200 A conforming to IEC 60947-4-1

Average Impedance 0.35 mOhm - Ith 250 A 50 Hz

Overvoltage category III

Operating time 35 ms closing for with LX1/LX9 coil / 130 ms opening for with LX1/LX9 coil / 30...40 ms closing for with LX4 coil / 30...50 ms opening for with LX4 coil / 40...80 ms closing for with LXE coil / 6...54 ms opening for with LXE coil

Maximum operating rate 2400 cyc/h 55 °C

Mounting Support Plate

Operating altitude 3000 m without derating

Key Features

High power motor

Higher work efficiency
