Tiandy TC-R3120 Lite-K 20 Channel NVR
Availability: In Stock

Tiandy TC-R3120 Lite-K 20 Channel NVR

Product SKU: TC-R3120
Rs.29,400

Safe Delivery

Quick & safe nation wide delivery

Easy Return

Hassle free return within 7 days

100% Original Product

Only genuine products, no compromises.

 WhatsApp Inquiry

Specifications

Type NVR
Channels 20 IP camera inputs
Max Resolution Support Up to 8MP
Video Compression S+265 / H.265 / S+264 / H.264
Audio Compression G711A / G711U / AAC / ADPCM_DIV4
Incoming Bandwidth 80 Mbps
Outgoing Bandwidth 80 Mbps
Preview Decoding Up to 1080P × 8 / 720P × 16 / 8MP × 2
Playback Decoding Up to 1080P × 8 / 720P × 16 / 8MP × 2
Video Output 1 × HDMI (up to 4K 3840×2160 @30Hz)
VGA Output 1 × VGA (up to 1080P)
Audio Input 1 × 3.5mm
Audio Output 1 × RCA
Two-Way Audio Supported via 3.5mm input
Multi-screen Display Up to 25 split views
HDD Support 1 × SATA (up to 10TB)
Disk Group 1 group
USB Ports 2 × USB 2.0
Network Interface 1 × RJ45 (10/100 Mbps)
Alarm I/O 4 × inputs, 1 × relay output
Remote Access Android / iOS / P2P
Protocols ONVIF, RTSP, TCP/IP, HTTP, HTTPS, DHCP, DNS, NTP, SNMP, SMTP, UPnP, etc.
Playback Functions Play, pause, stop, reverse, slow, fast, instant replay, digital zoom, backup editing
AI Analytics Tripwire, perimeter, face detection, people counting, loitering, vehicle/human classification, object detection
Operating Temperature -10°C ~ +55°C
Storage Temperature -20°C ~ +60°C
Humidity 10% ~ 90% RH (non-condensing)
Power Supply DC 12V / 3.33A
Power Consumption <10W (without HDD, idle)
Dimensions 255 × 231 × 45 mm
Weight Net 0.9 kg / Gross 1.6 kg

Key Features

20-channel IP camera support for large surveillance systems
Supports up to 8MP ultra-HD recording and playback
Advanced S+265 / H.265 / H.264 video compression
Incoming & outgoing bandwidth up to 80 Mbps
1 × SATA interface supporting up to 10TB HDD
AI-powered analytics (people counting, face detection, tripwire, perimeter protection, etc.)
1 × HDMI output supporting up to 4K resolution (3840×2160)
Multi-channel playback up to 16 channels simultaneously
ONVIF (Profile S/T/G) & RTSP compatibility for third-party cameras
Smart motion detection and alarm integration
Dual-stream recording for optimized storage and network efficiency
Remote access via Android, iOS, and P2P cloud platform
USB and network backup support with video export and editing
Advanced VCA search (face search, behavior search, early warning search)
Centralized camera management and cloud upgrade support
Product Details Reviews Shipping & Returns

Tiandy TC-R3120 Lite-K 20 Channel NVR

The TC-R3120 Tiandy Lite-K 20CH NVR is a high-performance surveillance recorder designed for medium to large-scale security systems. Supporting up to 20 IP camera channels and recording up to 8MP ultra-HD resolution, it delivers powerful monitoring, storage, and playback capabilities for professional security applications.

With advanced S+265/H.265 compression, this NVR significantly reduces storage usage while maintaining crystal-clear video quality. It supports HDMI 4K output, AI-powered video analytics, multi-channel playback, and ONVIF compatibility, making it suitable for commercial buildings, offices, warehouses, and large residential setups.
