Knox Xenon 12kw Pv16000w IP65 Hybrid Solar Inverter
Product SKU:
Knox-Xenon12kw-Pv16000w
Safe Delivery
Quick & safe nation wide delivery
Easy Return
Hassle free return within 7 days
100% Original Product
Only genuine products, no compromises.
Couldn't load pickup availability
Specifications
Type
Hybrid Solar Inverter
Phase
Single Phase
Dimensions (D x W x H)
210 x 435 x 665 mm
Net Weight
32 kg
Operating Temperature Range
-25°C to 60°C
Storage Temperature Range
-15°C to 60°C
Altitude
0 ~ 1000 m
Humidity
0 ~ 100% RH (Non-condensing)
Communication Ports
RS-232, RS-485, USB, CAN, Wi-Fi (optional), SNMP, Modbus
Intelligent Slot
Yes
Parallel Function
Yes, supports up to 9 units in parallel
Maximum PV Input Power
16000W
Rated Output Power
12000W / 12000VA
Maximum Charging Power
16000W
Nominal DC Voltage / Maximum DC Voltage
500 VDC
Start-up Voltage / Initial Feeding Voltage
80 VDC / 150 VDC
MPP Voltage Range
90 ~ 450 VDC
Number of MPP Trackers
2
Maximum Input Current per Tracker
18A
Nominal Output Voltage
220/230/240 VAC
Output Voltage Range
184 - 264.5 VAC or 195.5 - 253 VAC (Selectable)
Nominal Output Current
36A
Power Factor
0.9 lag ~ 0.9 lead
Surge Power
24000VA
No Load Power Consumption
< 85W
Maximum Conversion Efficiency (DC/AC)
96%
European Efficiency @ Nominal
95%
Transfer Time (for Personal Computers)
10 ms
Transfer Time (for Home Appliances)
20 ms
Output Waveform
Pure Sine Wave
Efficiency (DC to AC)
91%
Battery Voltage
48 VDC
Floating Charge Voltage
54 VDC
Overcharge Protection
66 VDC
Battery Voltage Range
40 ~ 62 VDC
Maximum Solar Charging Current
150A
Maximum AC Charging Current
150A
Maximum Charging Current
150A
Solar Charger Type
MPPT (Maximum Power Point Tracking)
Nominal Output Voltage
220/230/240 VAC
Output Voltage Range
184 - 264.5 VAC or 195.5 - 253 VAC (Selectable)
Efficiency
> 0.99
Frequency Range
50 Hz / 60 Hz (Auto sensing)
Surge Power
24000VA
AC Start-up Voltage / Auto Restart Voltage
120 - 140 VAC / 180 VAC
Acceptable Input Voltage Range
170 - 280 VAC (for Personal Computers) / 90 - 280 VAC (for Home Appliances)
Maximum AC Input Current
36A
IP Rating
IP65 (Dust and water-resistant, suitable for outdoor environments)
Cooling Method
Fan-assisted cooling for enhanced thermal management
Key Features
High power motor
Higher work efficiency
Product Details
Reviews
Shipping & Returns
Knox Xenon 12kw Pv16000w IP65 Hybrid Solar Inverter
dual output, making it perfect for both smart appliances and heavy-duty devices. With built-in Wi-Fi for online monitoring, it ensures real-time access to system performance. The Battery Management System (BMS) ensures safe and efficient integration with batteries when required.
This versatile inverter provides surge power capabilities and high conversion efficiency, making it an ideal choice for large-scale solar energy systems.
