SunFlx SH-S6K 6KW Single Phase Hybrid Solar Inverter IP65
Availability: In Stock

SunFlx SH-S6K 6KW Single Phase Hybrid Solar Inverter IP65

Product SKU: SH-S6K
Rs.215,000

Safe Delivery

Quick & safe nation wide delivery

Easy Return

Hassle free return within 7 days

100% Original Product

Only genuine products, no compromises.

 WhatsApp Inquiry

Specifications

Type Hybrid Solar Inverter
Phase Type Single Phase
Rated Output Power 6000W
Maximum AC Output Power 6600W
Peak Off-Grid Power 12KW (10 Seconds)
Battery Type Lithium Iron Phosphate (LiFePO4), Lead-Acid, Flooded, User Defined
Rated Battery Voltage 48V
Battery Voltage Range 40 – 60V
Maximum Battery Charge Current 135A
Maximum Battery Discharge Current 135A
Recommended PV Input Power 7800W
Maximum PV Input Voltage 500VDC
Start-Up Voltage 125VDC
MPPT Voltage Range 150 – 425VDC
Full Load PV Voltage Range 300 – 425VDC
Rated PV Input Voltage 370VDC
MPPT Input Current 18A + 18A
Maximum Short Circuit Current 27A + 27A
Number of MPPT Trackers 2
Strings per MPPT 1 + 1
Nominal AC Input Voltage 220/230VAC
Nominal Grid Frequency 50/60Hz (Auto Detection)
AC Input Voltage Range 180 – 270VAC
Maximum Bypass Current 40A
AC Rated Input/Output Current 27.3A / 26.1A
Maximum AC Input/Output Current 30A / 28.7A
Power Factor 0.8 Leading to 0.8 Lagging
Grid Type Single Phase
Total Harmonic Distortion (THD) <3%
No Load Power Consumption 100W
Grid DC Component <0.5% In
Maximum Efficiency 97.6%
European Efficiency 96.5%
MPPT Efficiency >99%
Protection Functions PV Arc Fault Detection, Anti-Islanding, DC Reverse Polarity Protection, Insulation Monitoring, Residual Current Monitoring, AC Overcurrent Protection, AC Short Circuit Protection
Surge Protection DC Type II / AC Type II
Operating Temperature Range -40°C to +60°C (Derating Above 45°C)
Cooling Method Smart Cooling (Heat Sink & Intelligent Fan)
Noise Level <50 dB
BMS Communication RS485 / CAN
Monitoring WiFi + APP
Dimensions (W × H × D) 346 × 416 × 250 mm
Weight 19kg

Key Features

6KW Single Phase Hybrid Solar Inverter
IP65 Weatherproof Protection
Dual MPPT Trackers
18A MPPT Input Current
Compatible with Lithium-Ion, Lead-Acid & Gel Batteries
On-Grid, Off-Grid & Hybrid Operation
Supports Up to 16 Units in Parallel
Dual AC Outputs for Smart Load Management
UPS-Level Backup Power
Supports Diesel Generator Input
Smart Color Touchscreen Display
WiFi Monitoring via SunFlx Cloud App
AC-Coupled, DC-Coupled & AC Retrofit Support
Multiple Energy Management Modes
Intelligent Battery Management System (BMS)
Product Details Reviews Shipping & Returns User Manual

SunFlx SH-S6K 6KW Single Phase Hybrid Solar Inverter IP65

The SunFlx SH-S6K is a next-generation 6KW Single Phase Hybrid Solar Inverter designed for residential solar energy storage applications. Built with an IP65-rated enclosure, it offers reliable indoor and outdoor operation while delivering efficient solar energy conversion and intelligent battery management.

Featuring dual MPPT trackers with 18A string current, the inverter supports larger solar panel arrays and maximizes energy harvesting. Compatible with Lithium-ion, Lead-acid, and Gel batteries, it provides flexible energy storage options to suit various installation requirements.

The SH-S6K supports on-grid, hybrid, and off-grid operating modes, making it a versatile solution for energy independence and backup power. With support for up to 16 units in parallel, users can easily expand system capacity. The inverter also integrates with the SunFlx Cloud App for real-time monitoring, remote configuration, and intelligent energy management.

SunFlx SH-S6K 6KW Single Phase Hybrid Solar Inverter Price In Pakistan
SunFlx SH-S6K 6KW Single Phase Hybrid Solar Inverter IP65
Looking to purchase SunFlx SH-S6K 6KW Single Phase Hybrid Solar Inverter IP65 in bulk?
  • Purchase Item in Bulk Quantity
  • Get At Best Price For Your Business
No reviews yet. Be the first to review this product.

Shipping

We ship across Pakistan. Standard delivery takes 3–7 business days.

Returns

Easy 7-day return policy. Product must be unused and in original packaging.

📄
Download User Manual
Click here to download PDF
