Sungrow On Grid 125Kw 3 Phase Inverter Price In Pakistan
  • Sungrow On Grid 125Kw 3 Phase Inverter Price In Pakistan
  • Sungrow On Grid 125Kw 3 Phase Inverter
Sungrow On Grid 125Kw 3 Phase Inverter
Availability: In Stock

Sungrow On Grid 125Kw 3 Phase Inverter

Product SKU: S125KW-ONGINVT
Rs.1,330,000

Safe Delivery

Quick & safe nation wide delivery

Easy Return

Hassle free return within 7 days

100% Original Product

Only genuine products, no compromises.

 WhatsApp Inquiry

Specifications

Type On-Grid (Grid-Tied) Inverter
Phase Three Phase
Recommended PV Power 175 kWp
Max. PV Input Voltage 1100 V
Min. PV Input / Start Voltage 180 V / 200 V
Rated PV Input Voltage 600 V
MPPT Voltage Range 180 – 1000 V
No. of MPPTs 12
Max PV Input Current 360 A (30 A × 12)
Max DC Short Circuit Current 480 A (40 A × 12)
Max Current per DC Connector 30 A
Rated Output Power 125 kW
Max AC Output Power 125 kVA
Max AC Output Current 181.1 A
Rated AC Voltage 3 / N / PE, 220 / 380 V – 230 / 400 V
AC Voltage Range 320 – 480 V
Grid Frequency 50 / 60 Hz
THD < 3%

Key Features

125kW three-phase on-grid solar inverter
High efficiency up to 98.5% (Euro efficiency 98.3%)
12 MPPT trackers for maximum energy optimization
Supports up to 175 kWp PV input capacity
Wide MPPT voltage range (180V – 1000V)
Built-in AFCI for advanced fire protection
PID recovery function for improved panel performance
Type I+II surge protection for enhanced safety
Smart monitoring via Bluetooth, RS485, WiFi & Ethernet
IP66 rated for dust & water resistance
High corrosion resistance (C5 grade)
Smart forced air cooling system
Supports optimizer & RSD compatibility (optional)
Suitable for large commercial & industrial solar systems
Product Details Reviews Shipping & Returns

Sungrow On Grid 125Kw 3 Phase Inverter

The Sungrow SG125CX-P2 125kW On-Grid Inverter is a high-capacity, industrial-grade solar solution designed for large commercial and utility-scale applications. Delivering a powerful 125kW AC output and up to 98.5% efficiency, this inverter ensures maximum energy conversion and optimized system performance.

Equipped with 12 independent MPPT trackers, it offers exceptional flexibility for complex solar installations, enabling maximum energy harvest even with varying panel orientations. Its wide MPPT voltage range (180V–1000V) and support for high PV input power up to 175 kWp make it ideal for large-scale solar plants.

Built with advanced protection systems including AFCI (Arc Fault Circuit Interrupter), PID recovery, and Type I+II surge protection, the SG125CX-P2 ensures superior safety and reliability. The IP66-rated enclosure, C5 anti-corrosion rating, and smart forced air cooling system make it highly durable in harsh environments.

With integrated smart monitoring via RS485, optional WiFi/Ethernet, and Bluetooth app support, users can easily monitor and control system performance in real time.
