Ai-Tek 1x4 Fiber Splitter Price is Rs.1,080/-. The Ai-Tek Fiber Optic Splirtter PLC 1×4 SC/APC 0.9mm 1Mtr is a premium-quality Planar Lightwave Circuit (PLC) splitter designed for efficient and reliable optical signal distribution. It evenly splits one input fiber into eight output fibers, making it ideal for FTTH, PON, LAN, and CATV networks. Featuring SC/APC connectors, a compact 0.9mm diameter design, and a 1-meter fiber length, this splitter offers low insertion loss and stable performance in high-density installations and limited spaces.
1×4 PLC splitter for distributing a single optical signal into eight outputs
SC/APC connectors for low back reflection and precise alignment
0.9mm tight buffer fiber ideal for compact routing and installations
1-meter length for flexible deployment
Uniform optical signal splitting with minimal signal loss
Excellent environmental and mechanical stability
Suitable for indoor and outdoor optical distribution networks
Compact and lightweight design
Plug-and-play installation
Compliant with Telcordia GR-1209 and GR-1221 standards
Product Specifications
Type
fiber splitter
model
ai-tek 1x4 plc fiber splitter
splitter type
plc (planar lightwave circuit)
configuration
1 input × 4 outputs
connector type
sc/apc
fiber type
single mode (g.657a1/g.652d optional)
operating wavelength
insertion loss
= 7.3 db
return loss
= 55 db
uniformity
= 0.8 db
polarization dependent loss (pdl)
= 0.2 db
directivity
= 55 db
fiber diameter
0.9 mm / 2.0 mm / 3.0 mm (as required)
cable length
standard 1 meter (custom lengths available)
operating temperature
-40°c to +85°c
storage temperature
-40°c to +85°c
compliance
telcordia gr-1209, gr-1221, rohs
Product Details
Ai-Tek 1x4 Fiber Splitter Price is Rs.1,080/-. The Ai-Tek Fiber Optic Splirtter PLC 1×4 SC/APC 0.9mm 1Mtr is a premium-quality Planar Lightwave Circuit (PLC) splitter designed for efficient and reliable optical signal distribution. It evenly splits one input fiber into eight output fibers, making it ideal for FTTH, PON, LAN, and CATV networks. Featuring SC/APC connectors, a compact 0.9mm diameter design, and a 1-meter fiber length, this splitter offers low insertion loss and stable performance in high-density installations and limited spaces.
