Autonics TCN4M-24R Digital PID Temperature Controller Price is Rs.36,000/-. The Autonics TCN4M-24R is a reliable and precise digital PID temperature controller designed for industrial automation systems. With auto-tuning functionality, it ensures optimal control without manual tuning. Its 1/8 DIN panel size (96 × 48 mm) makes it suitable for a wide range of equipment and machinery. It supports a variety of thermocouple and RTD sensor inputs and offers dual outputs-relay and SSR drive-making it highly versatile. The bright dual LED display allows easy monitoring of both process and set values.
4-Digits Large Dual Display for Setting & Indication
100ms high-speed sampling rate and ±0.5% display accuracy
24VAC/ 24-48 VDC (For TCN4S-22R only)
All ranges settable to 0C/0F
Both phase control & cycle control available as standard for SSR output
Compact design with large display panels for easier reading
Dual digital display (PV/SV)
High Speed Sampling 100ms
Indication Accuracy 0.5%
Memory Retention of Settings
Multi-Input type Selectable 4 input modes
Output mode ON/OFF & PID (Manual or Auto Tuning)
Output type Combined Relay + SSR output
PID Auto Tuning
Power Supply Voltage 100 to 240VAC 50/60HZ
SSR drive output (SSRP function) control options ON/OFF control, cycle control, phase control
Switch between relay output and SSR drive output
Two Alarm Output standard in all controllers
Product Specifications
Type
digital temperature controller
control method
pid, p, pi, pd, on/off (with auto-tuning)
input types
thermocouple (k, j, t, e, r, s, b, n, l), rtd (pt100, jpt100)
display
dual 4-digit 7-segment led (pv/sv)
output 1
relay (250v ac, 3a resistive load)
output 2
voltage (ssr drive, 12v dc ±2v, max. 20ma)
power supply
100–240v ac, 50/60 hz
panel size
1/8 din (96 × 48 mm)
mounting type
panel mount
operating temperature
-10°c to 50°c
Product Details
Autonics TCN4M-24R Digital PID Temperature Controller Price is Rs.36,000/-. The Autonics TCN4M-24R is a reliable and precise digital PID temperature controller designed for industrial automation systems. With auto-tuning functionality, it ensures optimal control without manual tuning. Its 1/8 DIN panel size (96 × 48 mm) makes it suitable for a wide range of equipment and machinery. It supports a variety of thermocouple and RTD sensor inputs and offers dual outputs-relay and SSR drive-making it highly versatile. The bright dual LED display allows easy monitoring of both process and set values.
