Display
|
led + app
|
|
ac current
|
max 92a
|
|
altitude
|
4000m
|
|
ambient humidity
|
0 - 100%, non-condensing
|
Couldn't load pickup availability
Ask About This Product
|
Display
|
led + app
|
|
ac current
|
max 92a
|
|
altitude
|
4000m
|
|
ambient humidity
|
0 - 100%, non-condensing
|
|
dc current
|
33a/33a/33a/33a
|
|
power factor (così )
|
å±0.8(adjustable)
|
|
ac power max
|
66kva
|
|
topology
|
transformerless
|
|
cooling method
|
cooling fans
|
|
current for input connector
|
max. 13a
|
|
current thd
|
< 3%
|
|
grid frequency
|
50/60hz
|
|
mppt voltage range (full load)
|
540-850vdc
|
|
number of dc connection sets per mppt
|
3/3/3/3
|
|
rated ac voltage
|
380v, 400v
|
|
rated ac voltage range
|
277v-520v
|
|
rated dc voltage
|
620vdc
|
|
start voltage
|
250vdc
|
|
communication
|
rs485(standard) / wi-fi & gprs
|
|
dc disconnection type
|
integrated switch
|
|
dc voltage max
|
1100vdc
|
|
efficiency class max
|
98.8% / euro ; 98.4%
|
|
grid connection type
|
3ë? / n(option) / pe
|
|
grid frequency range
|
45-55/55-65hz
|
|
number of mppt
|
4
|
|
operating temperature
|
-25å¡c to +60å¡c
|
|
protection
|
ingress
|
|
rated ac power
|
60kw
|
|
weight
|
67 kg
|
|
dimensions (w*h*d)
|
33.6 * 21.8 * 10.8 inch
|
