Circutor CVM-B100 Panel Mounted Power Analyzer
Product SKU:
CVM-B100
Rs.167,000
Safe Delivery
Quick & safe nation wide delivery
Easy Return
Hassle free return within 7 days
100% Original Product
Only genuine products, no compromises.
Couldn't load pickup availability
Specifications
Type
Power Analyzer
Model
CVM-B100
Measurement Type
Three-phase, 3 or 4-wire systems
Voltage Range
3 x 230/400 V AC
Current Input
Via external CTs (1 A or 5 A)
Frequency
50/60 Hz
Accuracy
Class 0.5 (Active Energy - IEC 62053-22)
Display
Backlit LCD, 96 x 96 mm front panel
Harmonic Measurement
Up to 31st order (voltage and current)
Communication
RS-485 (Modbus RTU)
Power Supply
100...277 V AC / DC
Outputs
2 transistor outputs (for alarms or pulse)
Mounting Type
Panel mount (DIN 96 x 96 mm)
Protection Degree
IP51 (front), IP30 (rear)
Operating Temperature
-10°C to +55°C
Key Features
Three-phase power analyzer with 4-quadrant measurement
Backlit LCD display with intuitive menu navigation
Class 0.5 accuracy for high-precision readings
Compatible with 1 A or 5 A external current transformers
DIN 96 x 96 mm panel mounting for easy installation
Harmonic analysis up to the 31st order
Ideal for switchboards, industrial panels, and energy audits
Measures voltage, current, power (active, reactive, apparent), energy, frequency, and power factor
RS-485 Modbus RTU communication for remote monitoring
Product Details
Reviews
Shipping & Returns
User Manual
Circutor CVM-B100 Panel Mounted Power Analyzer
The Circutor CVM-B100 is a multifunctional power analyzer designed for real-time monitoring of electrical parameters in three-phase low-voltage installations. With its 96 x 96 mm panel-mounted form factor and easy-to-read backlit LCD display, it provides accurate measurement of voltage, current, power, energy, and harmonics. Equipped with RS-485 Modbus RTU communication, it integrates seamlessly into energy management and SCADA systems. Suitable for industrial and commercial environments, the CVM-B100 ensures reliable data acquisition, energy efficiency, and system diagnostics with Class 0.5 accuracy.
