Clipsal AvatarOn Keycard Switch Price in Pakistan is Rs. 12,600/-.
Clipsal AvatarOn in color white, dark grey and wine gold is a key card switch, which is specially designed for hotels. Its fluorescent LED locator glows with a soft luminescence in the dark, indicating the exact location of the switch at night. The switch’s rated operation voltage is 250V and its rated current is 16A. It is 86 mm in width, 86 mm in height, and 43.8 mm in depth. And the embedding depth is 34.1 mm. The device mounting type can be either flush or surface. The device connection terminal is a brass terminal. The material it uses is PC (polycarbonate), characterizing high-impact strength. The standard of IEC 60669-2-1 is well satisfied.
Key card switch designed for hotels with fluorescent
LED locator for night visibility.
Rated voltage: 250V, rated current: 16A.
Compact dimensions: 86 mm (W) x 86 mm (H) x 43.8 mm (D).
Flush or surface mounting options.
Brass terminals for secure connections.
Made of high-impact polycarbonate (PC) material.
Complies with IEC 60669-2-1 standard.
Product Specifications
Range
avataron
product or component type
card switch
device application
load type
resistive
color tint
white, dark grey, wine gold
device presentation
complete product
rated current
16 a at 250 v ac 50 hz
connections - terminals
brass terminal
status led
led (amber)
polycarbonate
plastic part
device mounting
flush surface
width
86 mm
height
86 mm
depth
43.8 mm
embedding depth
34.1 mm
ip degree of protection
ip20
ambient air temperature for operation
0…40 °c
ambient air temperature for storage
0…60 °c
ambient air temperature for storage
0...60 °c
relative humidity
0…95 %
standards
iec 60669-2-1
