Elcontrol Energy Explorer Energy and Harmonic Analyzer Price is Rs.3,348,000/-. The Elcontrol Energy Explorer is a high-performance portable energy and harmonic analyzer designed for comprehensive power quality analysis and energy auditing in industrial and commercial electrical systems. Capable of monitoring voltage, current, power (kW, kVAR, kVA), energy (kWh), power factor, frequency, and harmonic distortion up to the 50th order, it provides accurate and real-time diagnostics of electrical parameters. Its large color display, intuitive interface, and extensive data logging capabilities make it ideal for energy managers, maintenance professionals, and auditors seeking to identify inefficiencies, detect disturbances, and optimize power usage. The Energy Explorer is equipped with multiple current clamp compatibility, USB/RS485 communication, and comes in a rugged, portable case for field use.Read More
Comprehensive analysis of energy and power quality
Advanced harmonic analysis up to the 50th order (voltage & current)
Built-in memory for extensive data logging and reporting
Communication via USB and RS485 (Modbus)
High-resolution TFT color display for real-time visualization
Measures voltage, current, frequency, power, energy, and power factor
Portable, rugged case for on-site use
Supports multiple current clamp inputs (up to 3000A)
User-friendly software for data download and reporting
Product Specifications
Type
analyzer
function
portable energy & harmonic analyzer
communication ports
usb, rs485 (modbus rtu)
current measurement
via external clamps (e.g., 100a to 3000a range)
data logging
large internal memory, programmable intervals
display
5.7" tft color display
enclosure
portable hard case for field applications
energy parameters
active and reactive energy (kwh, kvarh)
frequency range
45–65 hz
harmonic analysis
up to 50th order for voltage and current
power parameters
active, reactive, apparent power (kw, kvar, kva)
power supply
230v ac or via rechargeable battery (model dependent)
software
elcontrol pc software included
system compatibility
single-phase, three-phase balanced/unbalanced
voltage range
up to 600v (l-l)
Product Details
Elcontrol Energy Explorer Energy and Harmonic Analyzer Price is Rs.3,348,000/-. The Elcontrol Energy Explorer is a high-performance portable energy and harmonic analyzer designed for comprehensive power quality analysis and energy auditing in industrial and commercial electrical systems. Capable of monitoring voltage, current, power (kW, kVAR, kVA), energy (kWh), power factor, frequency, and harmonic distortion up to the 50th order, it provides accurate and real-time diagnostics of electrical parameters. Its large color display, intuitive interface, and extensive data logging capabilities make it ideal for energy managers, maintenance professionals, and auditors seeking to identify inefficiencies, detect disturbances, and optimize power usage. The Energy Explorer is equipped with multiple current clamp compatibility, USB/RS485 communication, and comes in a rugged, portable case for field use.
