Includes live circuit detection to prevent insulation test if voltage >30 V is detec...
Show All Key Features
Product Specifications
Type
digital multimeters
battery life
tester can perform at least 1000 insulation tests with fresh alkaline batteries at room temperature. these are standard tests of 1000 v into 1 mω with a duty cycle of 5 seconds on and 25 seconds off
Includes live circuit detection to prevent insulation test if voltage >30 V is detected
Includes auto-discharge of capacitive voltage for added user protection
Measures AC/DC voltage from 0.1 V to 600 V and resistance from 0.01 Ω to 20.00 kΩ
Provides lo-ohms earth-bond continuity (200 mA)
Simplifies repetitive or hard-to-reach testing with the remote test probe
Saves battery power with auto power off
Presents results on a large, backlit display
Features CAT IV 600 V overvoltage category rating
Comes with remote probe, test leads, test probes, alligator clips and one-year warranty
Accepts optional Fluke TPAK magnetic hanging system to free your hands for other work
Runs on four AA alkaline batteries (NEDA 15 A or IEC LR6) for at least 1000 insulation tests
Product Specifications
Type
digital multimeters
battery life
tester can perform at least 1000 insulation tests with fresh alkaline batteries at room temperature. these are standard tests of 1000 v into 1 mω with a duty cycle of 5 seconds on and 25 seconds off
storage temperature
-40°c to 60°c (-40°f to 140°f)
battery
four aa batteries (neda 15a or iec lr6)
measurement range
0.01 mω to 10 gω
operating temperature
-20°c to 55°c (-4°f to 131°f)
vibration
random, 2 g, 5-500 hz per mil-prf-28800f, class 2 instrument
