overload protection and surge capacity, handling up to twice the rated power for 5 seconds to support high-inrush loads. The inverter includes multiple charging modes, including a 3-step utility charging algorithm to efficiently manage battery charging for flooded, AGM, and gel batteries.
The inverter operates within a wide input voltage range of 170V to 280V AC and has a fast transfer time of 10 ms for UPS systems and 20 ms for appliances, minimizing any disruption during power transitions. Additionally, the compact design makes it easy to install, while its wide operating temperature range ensures reliable performance in various environmental conditions. Certified with CE, the inverter complies with international safety standards, providing peace of mind and long-term reliability.
Pure Sine Wave Output for stable power to sensitive electronics
High Efficiency with a peak of 94% for minimal energy loss
MPPT Solar Charging for efficient solar energy conversion
Surge Capacity handles up to 2x rated power for 5 seconds
Overload Protection with time-based limits for safety.
Utility and Solar Charging Modes with a 3-step charging algorithm
Fast Transfer Time of 10 ms for UPS and 20 ms for appliances
Wide Voltage Input Range from 170V to 280V AC.
High Charging Current up to 60A for rapid battery charging
Compact Design with dimensions of 390 mm x 270 mm x 100 mm and a weight of 5.4 kg
Wide Operating Temperature Range from -10°C to 50°C
CE Certified for international safety standards compliance
Product Specifications
Type
hybrid inverter
rated output power
3200 va / 3000 w
output voltage waveform
pure sine wave
output voltage regulation
230 vac ±5%
output frequency
50 hz
peak efficiency
94%
overload protection
5s at ≥150% load, 10s at 100%-150% load
surge capacity
2x rated power for 5s
nominal dc input voltage
24 vdc
cold start voltage
23.0 vdc
high dc recovery voltage
29 vdc
high dc cut-off voltage
30 vdc
no load power consumption
35 w
utility charging mode
3-step charging algorithm
ac charging current (maximum)
60 a (at 230 vac input)
bulk charging voltage (flooded battery)
29.2 vdc
bulk charging voltage (agm/gel battery)
28.2 vdc
floating charging voltage
27 vdc
maximum pv array power
3000 w
nominal pv voltage
240 vdc
pv array mppt voltage range
30 vdc – 400 vdc
max pv array open circuit voltage
400 vdc
maximum charging current
80 a
input voltage waveform
sinusoidal (utility or generator)
nominal input voltage
230 vac
low loss voltage
170 vac ±7v (ups), 90 vac ±7v (appliances)
low loss return voltage
180 vac ±7v (ups), 100 vac ±7v (appliances)
high loss voltage
280 vac ±7v
high loss return voltage
270 vac ±7v
maximum ac input voltage
280 vac
nominal input frequency
50 hz / 60 hz (auto detection)
low loss frequency
46 ±1 hz
low loss return frequency
47 ±1 hz
high loss frequency
54 ±1 hz
high loss return frequency
53 ±1 hz
output short circuit protection
circuit breaker
efficiency (line mode)
>95% (rated load, battery fully charged)
transfer time
10 ms for ups, 20 ms for appliances
safety certification
ce
operating temperature range
-10°c to 50°c
storage temperature
-15°c to 60°c
humidity
5% to 95% relative humidity (non-condensing)
dimensions (d x w x h)
390 mm x 270 mm x 100 mm
net weight
5.4 kg
Product Details
overload protection and surge capacity, handling up to twice the rated power for 5 seconds to support high-inrush loads. The inverter includes multiple charging modes, including a 3-step utility charging algorithm to efficiently manage battery charging for flooded, AGM, and gel batteries.
The inverter operates within a wide input voltage range of 170V to 280V AC and has a fast transfer time of 10 ms for UPS systems and 20 ms for appliances, minimizing any disruption during power transitions. Additionally, the compact design makes it easy to install, while its wide operating temperature range ensures reliable performance in various environmental conditions. Certified with CE, the inverter complies with international safety standards, providing peace of mind and long-term reliability.
