Fronius Infineon Reborn PV 7200 6.2kW Hybrid Inverter Price in Pakistan is Rs. 139,000/-. The Fronius Infineon Reborn PV 7200 6.2kW Hybrid Inverter is an advanced, high-performance energy management solution designed for larger residential and commercial solar power systems. With a rated output power of 6200W and peak efficiency of 93%, this inverter ensures optimal energy conversion while minimizing energy losses. It can handle maximum PV input power of up to 7200W, making it suitable for high-demand solar applications.
The inverter produces pure sine wave output, offering stable, clean power ideal for sensitive appliances and electronics. It features an impressive surge capacity of 12400W for 5 seconds, accommodating high-inrush loads like motors and compressors. With a robust overload protection system and 3-step charging algorithm, the inverter guarantees safe and efficient operation. It also supports MPPT solar chargi...
Pure Sine Wave Output for stable and clean power for sensitive equipment
High Efficiency with a peak efficiency of 93% for optimal energy conversion
Surge Capacity of 12,400W for 5 seconds, allowing support for high-inrush loads
MPPT Solar Charging supports up to 7200W of solar input for maximum energy harvesting
Overload Protection with time-based limits (3s at ≥150% load, 5s at 101%-150% load)
3-Step Charging Algorithm for optimized battery management and long-term battery health
Fast Transfer Time (10ms for UPS, 20ms for appliances), minimizing power disruptions
Grid-Tie Capabilities for feeding excess energy back to the grid with high power factor (>99)
Wide Input Voltage Range for compatibility with various battery configurations (46V–63V)
Maximum Conversion Efficiency (DC/AC) up to 97% for minimized energy losses
Compact Design for easy installation in residential or commercial solar systems
CE Certified, ensuring international safety and quality standards compliance
Product Specifications
Type
hybrid inverter
maximum pv input power
7200w
rated output power
6200w / 6200va
output voltage waveform
pure sine wave
output voltage regulation
230vac ±5%
output frequency
50hz
peak efficiency
93%
overload protection
3s at ≥150% load, 5s at 101%-150% load
surge capacity
12400w for 5s
nominal dc input voltage
48vdc
cold start voltage
46.0vdc
high dc recovery voltage
62vdc
high dc cut-off voltage
63vdc
no load power consumption
50w
full load output power
6200w
maximum main load
6200w
maximum second load (battery mode)
2066w
main load cut-off voltage
52vdc
main load return voltage
54vdc
utility charging mode
3-step charging algorithm
ac charging current (maximum)
100a (at 230vac input)
bulk charging voltage (flooded battery)
58.4vdc
bulk charging voltage (agm/gel battery)
56.4vdc
floating charging voltage
54vdc
maximum pv array power
7200w
nominal pv voltage
360vdc
pv array mppt voltage range
60vdc – 450vdc
max pv array open circuit voltage
500vdc
maximum charging current
120a
nominal output voltage
220/230/240vac
feed-in grid voltage range
195–253vac
feed-in grid frequency range
4951±1hz / 5961±1hz
nominal output current
26.9a
power factor range
>99
maximum conversion efficiency (dc/ac)
97%
input voltage waveform
sinusoidal (utility or generator)
nominal input voltage
230vac
low loss voltage
170vac ±7v (ups), 90vac ±7v (appliances)
low loss return voltage
180vac ±7v (ups), 100vac ±7v (appliances)
high loss voltage
280vac ±7v
high loss return voltage
270vac ±7v
maximum ac input voltage
300vac
nominal input frequency
50hz / 60hz (auto detection)
low loss frequency
40 ±1hz
low loss return frequency
42 ±1hz
high loss frequency
65 ±1hz
high loss return frequency
63 ±1hz
output short circuit protection
circuit breaker
efficiency (line mode)
>95% (rated load, battery fully charged)
transfer time
10ms for ups, 20ms for appliances
safety certification
ce
operating temperature range
-10°c to 50°c
storage temperature
-15°c to 60°c
humidity
5% to 95% relative humidity (non-condensing)
dimensions (d x w x h)
450mm x 350mm x 110mm
net weight
10.0 kg
Product Details
Fronius Infineon Reborn PV 7200 6.2kW Hybrid Inverter Price in Pakistan is Rs. 139,000/-. The Fronius Infineon Reborn PV 7200 6.2kW Hybrid Inverter is an advanced, high-performance energy management solution designed for larger residential and commercial solar power systems. With a rated output power of 6200W and peak efficiency of 93%, this inverter ensures optimal energy conversion while minimizing energy losses. It can handle maximum PV input power of up to 7200W, making it suitable for high-demand solar applications.
The inverter produces pure sine wave output, offering stable, clean power ideal for sensitive appliances and electronics. It features an impressive surge capacity of 12400W for 5 seconds, accommodating high-inrush loads like motors and compressors. With a robust overload protection system and 3-step charging algorithm, the inverter guarantees safe and efficient operation. It also supports MPPT solar charging, ensuring maximum solar energy harvesting.
With grid-tie capabilities, the inverter seamlessly integrates into utility networks, providing excess energy to the grid and contributing to energy independence. The inverter operates in a wide voltage range, from 46V to 63V for the DC input, ensuring compatibility with different battery configurations. Additionally, it offers fast transfer times for UPS systems (10ms) and appliances (20ms), ensuring minimal disruption during power transitions.
Designed for long-term reliability, the Fronius Infineon Reborn PV 7200 features a compact design, wide operating temperature range, and compliance with CE safety standards, ensuring that it meets international quality and safety expectations.
