Himel HDM3E 1600A Frame 4 Pole MCCB Breakers Price in Pakistan is Rs. 350,000/-. The Himel HDM3E 1600A 4-Pole Enclosed Molded Case Circuit Breaker (MCCB) is designed for high-capacity power distribution and protection in industrial and commercial electrical systems. It features advanced electronic trip unit technology with adjustable protection settings, delivering precise, reliable defense against overloads, short circuits, and ground faults. With its high-breaking capacity and rugged construction, this MCCB is ideal for demanding applications requiring operational reliability and safety compliance.
4-pole design for comprehensive phase and neutral protection
High rated current options: 1000A, 1250A, 1600A
Electronic trip unit for precise and adjustable protection
High breaking capacity: 50 kA at 400/415 V AC
Short-time withstand current: 42 kA for 1 second
Excellent mechanical (12,500 cycles) and electrical (6,000 cycles) durability
Wide voltage tolerance with 1000V insulation and 12kV impulse withstand
Compact dimensions: 327 mm (H) x 280 mm (W) x 190 mm (D)
Conforms to IEC 60947-1 and IEC 60947-2 standards
Suitable for industrial, commercial, and critical infrastructure use
Product Specifications
Product type
enclosed molded case circuit breaker
poles
4p
rated current [in]
1000a, 1250a, 1600a
trip unit technology
electronic
rated operational voltage [ue]
400/415 v ac
network type
ac
network frequency
50 hz
rated insulation voltage [ui]
1000 v
rated impulse withstand voltage [uimp]
12 kv
ultimate breaking capacity [icu]
50 ka
service breaking capacity [ics]
50 ka
short-time withstand current [icw]
42 ka (1 second duration)
mechanical durability
12,500 cycles
electrical durability
6,000 cycles (at 400/415 v ac)
height
327 mm
width
280 mm
depth
190 mm
standards compliance
iec 60947-1, iec 60947-2
degree of protection
ip20
installation type
fixed, enclosed
Product Details
Himel HDM3E 1600A Frame 4 Pole MCCB Breakers Price in Pakistan is Rs. 350,000/-. The Himel HDM3E 1600A 4-Pole Enclosed Molded Case Circuit Breaker (MCCB) is designed for high-capacity power distribution and protection in industrial and commercial electrical systems. It features advanced electronic trip unit technology with adjustable protection settings, delivering precise, reliable defense against overloads, short circuits, and ground faults. With its high-breaking capacity and rugged construction, this MCCB is ideal for demanding applications requiring operational reliability and safety compliance.
