The Hyundai UAB50SF 3 Pole Molded Case Circuit Breaker offers reliable electrical protection with a breaking capacity of 25 KA at 380-400V and 6.25 KA at 415V. With a frame size of 50Amps and a weight ranging from 0.6 to 0.96 kg, it strikes a balance between compactness and functionality. Operating at a rated operational voltage of AC660V or DC250V, it ensures consistent performance across different electrical systems. Available in various current ratings from 15A to 50A, it caters to a wide range of industrial applications. Equipped with overload, instantaneous, and short-circuit protection, it safeguards electrical circuits from damage. Rated for impulse voltage of 6 and insulation voltage of AC690V, it offers reliable operation in diverse conditions. As part of the U Series+ lineup, it reflects Hyundai's commitment to quality and innovation in electrical protection solutions.
Reliable electrical protection with high breaking capacity
Compact design, weight ranges from 0.6 to 0.96 kg
Rated operational voltage AC660V or DC250V
Available in current ratings from 15A to 50A
Overload, instantaneous, and short-circuit protection
Impulse voltage rating 6, insulation voltage: AC690V
Part of Hyundai's U Series+ lineup, ensuring quality and innovation.
Product Specifications
Type
mccb breaker
breaking capacity
25 ka / 6.25 ka (380-400v) 25 ka / 6.25 ka (415v)
frame size
50amps
weight
0.6/0.78/0.96 kg
rated operational voltage
ac660 v/ dc250
current rating
12.5 to 16a, 20 to 25a, 25 to 32a, 32 to 40a, 40 to 50a
number of poles
3 poles
protection
overload, inst., short-circuit\
rated impulse voltage
Product Details
The Hyundai UAB50SF 3 Pole Molded Case Circuit Breaker offers reliable electrical protection with a breaking capacity of 25 KA at 380-400V and 6.25 KA at 415V. With a frame size of 50Amps and a weight ranging from 0.6 to 0.96 kg, it strikes a balance between compactness and functionality. Operating at a rated operational voltage of AC660V or DC250V, it ensures consistent performance across different electrical systems. Available in various current ratings from 15A to 50A, it caters to a wide range of industrial applications. Equipped with overload, instantaneous, and short-circuit protection, it safeguards electrical circuits from damage. Rated for impulse voltage of 6 and insulation voltage of AC690V, it offers reliable operation in diverse conditions. As part of the U Series+ lineup, it reflects Hyundai's commitment to quality and innovation in electrical protection solutions.
