The Hyundai UCB100LF 3 Pole High Breaking Capacity MCCB Breaker offers a wide production range from 50 to 125A, with 5 to 150kA at AC415V. It covers the Hi-Series MCCB range with enhanced characteristics and optimized design, enabling high breaking capacity in a compact size. With minimized effects from fault currents and easy replacement, it ensures cost-effectiveness and versatility. Type-tested by international authorities and with various marine certifications, it's suitable for diverse applications, from general distribution boards to nuclear power plants.
Wide production range: 3 to 1600A, 5 to 150kA at AC415V.
Covers Hi-Series MCCB range with better characteristics.
Optimized design for high breaking capacity in a smaller size.
Minimizes effects from fault currents, ensuring cost-effectiveness.
Easy replacement with minimized size difference between models.
Product Specifications
Type
mccb breaker
breaking capacity
50 ka / 37.5 ka (380-400v) 50 ka / 37.5 ka (415v)
weight
0.9/1.0/1.3 kg
rated operational voltage
ac 660v / dc 250v
number of poles
3 poles
protection
overload, inst., short-circuit
rated impulse voltage
6
rated insulation voltage
ac690 v
series
u series+
Product Details
The Hyundai UCB100LF 3 Pole High Breaking Capacity MCCB Breaker offers a wide production range from 50 to 125A, with 5 to 150kA at AC415V. It covers the Hi-Series MCCB range with enhanced characteristics and optimized design, enabling high breaking capacity in a compact size. With minimized effects from fault currents and easy replacement, it ensures cost-effectiveness and versatility. Type-tested by international authorities and with various marine certifications, it's suitable for diverse applications, from general distribution boards to nuclear power plants.
