Hyundai 3P MCCB Breaker Price in Pakistan is Rs. 280,000/-. The Hyundai UCB800RF 3 Pole Molded Case Circuit Breaker is engineered to deliver reliable protection for electrical circuits in a variety of applications. With an impressive breaking capacity of 45 KA / 23 KA (380-400V) and 45 KA / 23 KA (415V), it ensures safe operation even under high-stress conditions. Available in rated currents of 700A and 800A, it caters to a wide range of power requirements. Its compact frame size of 800Amps, with dimensions of 280mm (height) x 110mm (depth) x 210mm to 280mm (width), offers a balance of power and space efficiency. Constructed for durability, it features a sturdy build while maintaining a manageable weight ranging from 8.7 to 12.5 kg. Equipped with 3 Poles, it provides comprehensive protection against overload, instantaneous, and short-circuit faults. With a rated operational voltage of AC660V and rated insulation voltage of AC690V...
High breaking capacity of 45 KA / 23 KA (380-400V) and 45 KA / 23 KA (415V)
Rated currents available in 700A and 800A
Compact frame size of 800Amps
Sturdy construction with manageable weight
Three poles for comprehensive protection
Safeguards against overload, instantaneous, and short-circuit faults
Rated operational voltage of AC660V
Rated insulation voltage of AC690V
Part of Hyundai's reliable U Series+
Product Specifications
Type
mccb breaker
breaking capacity
45 ka / 23 ka (380-400v) 45 ka / 23 ka (415v)
rated current
700, 800
height
280
depth
110
frame size
800amps
weight
8.7/9.5/12.5 kg
rated operational voltage
ac660 v/ dc250
current rating
400 to 500a, 504 to 630a
number of poles
3 poles
protection
overload, inst., short-circuit
rated impulse voltage
6
rated insulation voltage
ac690 v
series
u series+
width
210/210/280
Product Details
Hyundai 3P MCCB Breaker Price in Pakistan is Rs. 280,000/-. The Hyundai UCB800RF 3 Pole Molded Case Circuit Breaker is engineered to deliver reliable protection for electrical circuits in a variety of applications. With an impressive breaking capacity of 45 KA / 23 KA (380-400V) and 45 KA / 23 KA (415V), it ensures safe operation even under high-stress conditions. Available in rated currents of 700A and 800A, it caters to a wide range of power requirements. Its compact frame size of 800Amps, with dimensions of 280mm (height) x 110mm (depth) x 210mm to 280mm (width), offers a balance of power and space efficiency. Constructed for durability, it features a sturdy build while maintaining a manageable weight ranging from 8.7 to 12.5 kg. Equipped with 3 Poles, it provides comprehensive protection against overload, instantaneous, and short-circuit faults. With a rated operational voltage of AC660V and rated insulation voltage of AC690V, it ensures safe and efficient operation. The UCB800RF, part of Hyundai's trusted U Series+, is a reliable choice for critical electrical systems.
