Inter Digital Multi-Measurement Meter Price in Pakistan Rs 42,100/-. The Inter PM-3DM96 Digital Multi-Measurement Meter is a high-precision, multifunctional power analyzer designed for monitoring and displaying critical electrical parameters in 3-phase systems. Housed in a standard 96x96mm panel mount casing, this meter offers real-time measurement of voltage, current, power (kW, kVAR, kVA), frequency, power factor, and energy consumption (kWh). With advanced True RMS sensing and optional RS-485 Modbus communication, it is ideal for industrial automation, energy management systems, and power factor correction panels where accurate, reliable monitoring is essential.
Comprehensive 3-phase monitoring in one compact unit
Bright digital display for easy readability
DIN standard 96x96mm design fits easily into control panels
Energy consumption tracking (kWh) for cost management
Ideal for industrial, commercial, and utility power monitoring
Optional RS-485 Modbus communication for remote access and system integration
Quick and easy installation
True RMS measurement for accurate readings
Wide input voltage and current compatibility
Product Specifications
Type
multi measurement meter
display type
clear led or lcd screen (model-specific)
accuracy
voltage/current
communication (optional)
rs-485 modbus rtu
enclosure protection
ip52 (front), ip20 (rear)
input configuration
3-phase 3-wire / 4-wire systems
input current
1a / 5a via external ct
measurement capabilities
voltage (line-to-line, line-to-neutral), current (per phase and total), frequency (hz), active power (kw), reactive power (kvar), apparent power (kva), power factor (individual and total), energy measurement (kwh)
measurement method
true rms
mounting type
din panel mount
operating temperature
-10°c to +60°c
panel size
96 x 96 mm
power supply
85–265v ac or 100–300v dc
voltage input range
100–500v ac
Product Details
Inter Digital Multi-Measurement Meter Price in Pakistan Rs 42,100/-. The Inter PM-3DM96 Digital Multi-Measurement Meter is a high-precision, multifunctional power analyzer designed for monitoring and displaying critical electrical parameters in 3-phase systems. Housed in a standard 96x96mm panel mount casing, this meter offers real-time measurement of voltage, current, power (kW, kVAR, kVA), frequency, power factor, and energy consumption (kWh). With advanced True RMS sensing and optional RS-485 Modbus communication, it is ideal for industrial automation, energy management systems, and power factor correction panels where accurate, reliable monitoring is essential.
