Inter Digital Energy Analyzer Price in Pakistan Rs 145,100/-. The Inter PM-PACG96 Digital Dual Tariff Energy Analyzer is a high-precision power monitoring instrument designed to measure and display key electrical parameters including active energy consumption under two different tariffs. Featuring dual energy counters, it is ideal for distinguishing peak and off-peak energy usage, allowing for efficient energy management and cost control. With its 96x96 mm panel-mounted design, clear digital display, and advanced functionality, the PM-PACG96 is well-suited for industrial, commercial, and utility applications where dual-rate billing is implemented.
Dual energy counters for two-rate (peak/off-peak) energy monitoring
Accurate and reliable Class 1.0 measurement
Compact 96x96 mm DIN panel mount design
External control input for tariff switching
High-visibility LED/LCD screen for clear parameter display
Ideal for utility billing, industrial energy audits, and cost allocation
Measures full range of electrical parameters including power and energy
Optional RS-485 Modbus RTU communication for remote monitoring
Product Specifications
Type
digital energy analyzer
display type
4-digit led or lcd (model dependent)
accuracy class
class 1.0 (active energy)
communication
rs-485 modbus rtu (optional)
current input
via external cts (typically 5a or 1a secondary)
energy counters
2 independent tariff counters (t1 and t2)
housing material
flame-retardant abs plastic
measurement parameters
voltage, current, frequency, power factor, active/reactive/apparent power, active energy (dual tariff)
mounting type
panel mount (96 x 96 mm)
operating temperature
-10°c to +55°c
power supply
85 – 265v ac / 50–60hz
protection degree
ip20 (front panel optionally ip54 with gasket)
pulse output
1 or 2 programmable pulse outputs
tariff control
external digital input for switching between t1/t2
voltage input
3-phase 3/4-wire, 80v – 500v ac (ph-ph)
Product Details
Inter Digital Energy Analyzer Price in Pakistan Rs 145,100/-. The Inter PM-PACG96 Digital Dual Tariff Energy Analyzer is a high-precision power monitoring instrument designed to measure and display key electrical parameters including active energy consumption under two different tariffs. Featuring dual energy counters, it is ideal for distinguishing peak and off-peak energy usage, allowing for efficient energy management and cost control. With its 96x96 mm panel-mounted design, clear digital display, and advanced functionality, the PM-PACG96 is well-suited for industrial, commercial, and utility applications where dual-rate billing is implemented.
