Inter Energy Analyzer Price in Pakistan Rs 125,100/-. The Inter PM-PAG96 Digital Dual Tariff Energy Analyzer is a versatile and accurate power monitoring device designed to measure and record electrical energy consumption under two different tariff conditions. This dual counter system allows users to differentiate energy usage during peak and off-peak hours, enabling more effective energy management and cost optimization. Its compact 96x96 mm panel design, digital display, and support for external control inputs make it ideal for industrial, commercial, and utility-based applications where multi-tariff energy tracking is required.
Dual tariff energy metering (T1 & T2) for peak/off-peak tracking
Bright digital display for easy viewing
Compact 96x96 mm panel design for easy installation
High accuracy Class 1.0 compliance
Ideal for smart billing, load analysis, and energy audits
Measures key electrical parameters in real-time
Optional RS-485 communication for remote data access
Pulse output for energy management systems
Supports external control for tariff switching
Product Specifications
Type
energy analyzer
display type
bright 4-digit led or lcd (model specific)
accuracy class
class 1.0 (active energy)
communication port
rs-485 modbus rtu (optional)
current input
through external ct (1a or 5a secondary)
enclosure material
flame-retardant abs plastic
humidity
=85% rh (non-condensing)
measurement parameters
voltage, current, frequency, power factor, active/reactive/apparent power, active energy
mounting type
din panel mount (96 x 96 mm)
operating temperature
-10°c to +55°c
output
programmable pulse output
power supply
85–265v ac, 50/60 hz
protection degree
ip20 front (ip54 optional with gasket)
tariff control input
digital input for external tariff switching
tariff counters
dual energy counters (t1 and t2)
voltage input range
80v – 500v ac (phase-to-phase)
Product Details
Inter Energy Analyzer Price in Pakistan Rs 125,100/-. The Inter PM-PAG96 Digital Dual Tariff Energy Analyzer is a versatile and accurate power monitoring device designed to measure and record electrical energy consumption under two different tariff conditions. This dual counter system allows users to differentiate energy usage during peak and off-peak hours, enabling more effective energy management and cost optimization. Its compact 96x96 mm panel design, digital display, and support for external control inputs make it ideal for industrial, commercial, and utility-based applications where multi-tariff energy tracking is required.
