Inter Digital Auto-Tuning Temperature Controller Price in Pakistan Rs 50,500/-. The Inter PM-TC48 Digital Auto-Tuning Temperature Controller is a compact and reliable PID-based temperature control unit designed for precise and stable thermal management in a wide range of industrial applications. With auto-tuning functionality, it intelligently adjusts PID parameters for optimal performance, minimizing overshoot and response time. The 48x48 mm DIN-standard size, dual display (PV/SV), and universal sensor input (thermocouples or RTDs) make it ideal for integration into ovens, heaters, furnaces, plastics machinery, and HVAC systems. Simple setup, flexible output options, and a robust build ensure long-term, trouble-free operation.
Auto-tuning PID control for fast, accurate temperature regulation
Compact 48x48 mm panel design ideal for space-limited setups
Dual LED display for real-time process and setpoint values
Easy front-panel configuration and parameter setup
Programmable alarm settings for process safety
Rugged design for continuous industrial use
Selectable output modes including relay, SSR, or analog signals
Universal input supports thermocouples and RTDs
Wide voltage support and power stability
Product Specifications
Type
digital temperature controller
panel size
48 x 48 mm (din standard)
accuracy
±0.5% of full scale
alarm functions
configurable high/low/offset alarms
control mode
on/off, pid, manual
control output
relay / ssr / 4–20 ma / 0–10v (selectable models)
control type
pid with auto-tuning
display
dual 4-digit led (pv & sv)
input signal
universal (configurable)
mounting type
panel mount
operating temperature
0°c to +50°c
output action
heating / cooling
power supply
85–265v ac / 24v dc (model dependent)
protection class
ip54 (front), ip20 (rear)
sensor input
thermocouple (k, j, t, etc.) / rtd (pt100)
Product Details
Inter Digital Auto-Tuning Temperature Controller Price in Pakistan Rs 50,500/-. The Inter PM-TC48 Digital Auto-Tuning Temperature Controller is a compact and reliable PID-based temperature control unit designed for precise and stable thermal management in a wide range of industrial applications. With auto-tuning functionality, it intelligently adjusts PID parameters for optimal performance, minimizing overshoot and response time. The 48x48 mm DIN-standard size, dual display (PV/SV), and universal sensor input (thermocouples or RTDs) make it ideal for integration into ovens, heaters, furnaces, plastics machinery, and HVAC systems. Simple setup, flexible output options, and a robust build ensure long-term, trouble-free operation.
