Type
|
solar charger
|
|
capacity
|
1600w
|
|
voltage
|
230 vac
|
|
selectable voltage range
|
90-280 vac
|
Couldn't load pickup availability
Ask About This Product
|
Type
|
solar charger
|
|
capacity
|
1600w
|
|
voltage
|
230 vac
|
|
selectable voltage range
|
90-280 vac
|
|
frequency range
|
50 hz / 60 hz (auto sensing)
|
|
ac voltage regulation (battery mode)
|
230 vac ± 10%
|
|
efficiency (peak)
|
85%
|
|
transfer time
|
20 ms
|
|
waveform
|
simulated sine wave
|
|
battery voltage
|
12 vdc
|
|
floating charge voltage
|
27.4 vdc ± 0.5 vdc
|
|
overcharge protection
|
30.0vdc ± 1 vdc
|
|
solar charger type
|
mppt
|
|
maximum pv array open circuit voltage
|
100 vdc
|
|
maximum pv array power
|
1200w
|
|
mpp range @ operating voltage
|
30 - 80 vdc
|
|
maximum solar charge current
|
50a
|
|
maximum ac charge current
|
10a / 20a
|
|
maximum charge current
|
50a
|
|
dimensions (d x w x h)
|
272 x 212 x 127 mm
|
|
net weight
|
4.8 kg
|
|
humidity
|
0 to 95% rh (non-condensing)
|
|
operating temperature
|
0°c to 40°c
|
|
storage temperature
|
-15°c to 50°c
|
