Type
|
solar inverter
|
|
rated power
|
7200 watts
|
|
input voltage
|
230 vac
|
|
adjustable voltage range
|
170 – 280 vac for personal computers, 90 – 280 vac for standard home appliances
|
The surge power ratio by the Sunbridge PV8000 is around 16K VA.
Conversion Efficiency: The sustained efficiency reach of DC to AC power conversion is from 90% – 93%.
Transfer Time: for the personal computers, the transfer time delivered is up to 15 ms—likewise, it can reach up to 20 ms for standard home appliances.
The pure sine wave is used as the output waveform that ensures much compact efficiency than the competing solar inverters.
The range of battery voltage used in the DC to AC inverter is up to 48 VDC. On a side note, the floating charge voltage has the highest ratio of 54 VDC.
Most of the cases are noted to be critical, causing massive losses, because of battery to circuit burning—these happen as the overflow of charge through the circuit. In the modern solar technology, it can be inhibited by the help of an overcharge protection feature. The Sunbridge PV8000 restricts the charge flow over 68 VDC, thus ensuring safe circuits.
The type of solar charge used in the Sunbridge Solar Inverter is MPPT. The maximum open-circuit voltage by the PV array is 500 VDC. Also, the maximum PV array power generated by the DC inverter is 8k Watts (4000 W X 2). The operating voltage range of the MPPT module is 90 ~ 450 VDC. The maximum solar charge current, AC charge current, and plain charge current delivered by the AC inverter are 80 amperes, respectively.
As the solar panel inverter is heavier than the ordinary inverters for household use—the net weight is 41 lbs. The structure of the model is compact, ensuring durability and extended life expectancy. It has enabled a USB/RS232 port for the communication interface.
The humidity tolerance of the Sunbridge PV8000 solar inverter is 5% to 95%. Likewise, it can efficiently operate in a temperature range of -10° to 50°C. For the storage, the range moves from -15° to 60° C.
