Type
|
on grid solar inverter
|
|
rated power
|
11000va/11000w
|
|
parallel capability
|
yes, 6 units
|
|
voltage
|
230 vac
|
Couldn't load pickup availability
Ask About This Product
|
Type
|
on grid solar inverter
|
|
rated power
|
11000va/11000w
|
|
parallel capability
|
yes, 6 units
|
|
voltage
|
230 vac
|
|
selectable voltage range
|
170-280 vac (for personal computers), 90-280 vac (for home appliances)
|
|
frequency range
|
50 hz/60 hz (auto sensing)
|
|
ac voltage regulation (batt. mode)
|
230vac ± 5%
|
|
surge power
|
22000va
|
|
efficiency
|
93%
|
|
transfer time
|
10 ms (for personal computers); 20 ms (for home appliances)
|
|
waveform
|
pure sine wave
|
|
battery voltage
|
48 vdc
|
|
floating charge voltage
|
54 vdc
|
|
overcharge protection
|
63 vdc
|
|
solar charger type
|
mppt
|
|
maximum pv array power
|
12000w (6000w x 2)
|
|
mppt range @ operating voltage
|
90 ~ 450 vdc
|
|
maximum pv array open circuit voltage
|
500 vdc
|
|
maximum pv input current
|
27a x 2 (max 40a)
|
|
maximum solar charge current
|
150a
|
|
maximum ac charge currentl
|
150a
|
|
maximum charge current
|
150a
|
|
dimension, d x w x h (mm)
|
145 x 438 x 553.6
|
|
net weight (kgs)
|
18.4
|
|
communication interface
|
usb/rs232/rs485/wifi/dry-contact/bts, support optional gfci, rapid shutdown, afci detection
|
|
external current sensor port
|
yes, built-in current transformer sensor
|
|
humidity
|
5% to 95% relative humidity(non-condensing)
|
|
operating temperature
|
-10°c to 50°c
|
|
storage temperature
|
-15°c to 60°c
|
|
compliance safety
|
ce
|
