Type
|
on grid solar inverter
|
|
rated power
|
4000va/4000w
|
|
voltage
|
230 vac
|
|
selectable voltage range
|
170-280 vac (for personal computers), 90-280 vac (for home appliances)
|
Couldn't load pickup availability
Ask About This Product
|
Type
|
on grid solar inverter
|
|
rated power
|
4000va/4000w
|
|
voltage
|
230 vac
|
|
selectable voltage range
|
170-280 vac (for personal computers), 90-280 vac (for home appliances)
|
|
frequency range
|
50 hz/60 hz (auto sensing)
|
|
ac voltage regulation (batt. mode)
|
230vac ± 10%
|
|
surge power
|
8000va
|
|
efficiency
|
90%-93%
|
|
transfer time
|
10 ms (for personal computers), 20 ms (for home appliances)
|
|
waveform
|
pure sine wave
|
|
battery voltage
|
24 vdc
|
|
floating charge voltage
|
27 vdc
|
|
overcharge protection
|
33 vdc
|
|
solar charger type
|
mppt
|
|
maximum pv array open circuit voltage
|
500 vdc
|
|
maximum pv array power
|
5000w
|
|
mpp range @ operating voltage
|
60-450 vdc
|
|
maximum pv input current
|
27a
|
|
maximum solar charge current
|
120a
|
|
maximum ac charge current
|
100a
|
|
maximum charge current
|
120a
|
|
dimension, d x w x h (mm)
|
119 x 313.6 x 457.5
|
|
net weight (kgs)
|
10
|
|
communication interface
|
usb/rs232/rs485/wifi/dry-contact
|
|
humidity
|
5% to 95% relative humidity(non-condensing)
|
|
operating temperature
|
-10°c to 50°c
|
|
storage temperature
|
-15°c to 60°c
|
