and high performance, making it a reliable choice for maximizing solar energy utilization and ensuring efficient power management in various applications.
Two independent AC power sources are connected and switched automatically
Built-in current transformer sensor to meet self-consumption application
Support external BTS (Battery Temperature Sensor) detection
Built-in power status lighting indicators
Built-in 2.8" colored LCD with slide operation
Support optional GFCI, Rapid shutdown, AFCI detections
Parallel operation with 6 units
Built-in WiFi with remote monitoring APP
Grid Feeding
Supports USB On-the-Go function reserved
communication port for BMS (RS485, CAN-BUS or RS232)
Product Specifications
Type
on grid solar inverter
phase
1-phase in / 1-phase out
maximum pv input power
7000w
rated output power
6000w
maximum charging power
6000w
nominal dc voltage / maximum dc voltage
360 vdc / 500 vdc
start-up voltage / initial feeding voltage
110vdc / 120 vdc
mpp voltage range
120 vdc ~ 430 vdc
number of mpp trackers / maximum input current
1 / 27 a
nominal output voltage
220/230/240 vac
output voltage range
184 - 264.5 vac or 195.5 - 253 vac (selectable)
nominal output current
26a
power factor
> 0.9
ac start-up voltage / auto restart voltage
120-140 vac/180vac
maximum conversion efficiency (dc/ac)
96%
ac start-up voltage/ auto restart voltage
120 - 140 vac / 180 vac
acceptable input voltage range
90 - 280 vac or 170 - 280 vac
maximum ac input current
40 a
maximum dc voltage
500 vdc
mpp voltage range
120 vdc ~ 430 vdc
number of mpp trackers / maximum input current
1 / 27 a
nominal output voltage
220/230/240 vac
output voltage range
184- 264.5 vac or 195.5 = 253 vac (selectable)
nominal dc voltage / maximum dc voltage
360 vdc / 500 vdc
start-up voltage / initial feeding voltage
110vdc / 120 vdc
mpp voltage range
120 vdc ~ 430 vdc
number of mpp trackers / maximum input current
1 / 27 a
nominal output voltage
220/230/240 vac
output voltage range
184 - 264.5 vac or 195.5 - 253 vac (selectable)
nominal output current
26a
ac start-up voltage / auto restart voltage
120 - 140 vac / 180 vac
acceptable input voltage range
90 - 280 vac or 170 - 280 vac
maximum ac input current
40a
nominal output voltage
220/230/240 vac
efficiency (dc to ac)
93%
nominal dc voltage
48 vdc
maximum solar charging current
120a
maximum ac charging current
120a
maximum charging current
120a
dimension, d x w x h (mm)
140 x 295 x 468
net weight (kgs)
12
parallel function
yes, 9 units
communication port
usb/rs232/rs485/wifi/dry-contact
humidity
0 ~ 90% rh (non-condensing)
operating temperature
-10 to 50ºc
