include IP65 protection and convective fans for durability. Backed by certifications and boasting high efficiency, it's an ideal choice for solar grid-tied systems.
One-button safety setting for user-friendly operation
Integrated RTC chip for data storage
IP65 protection for indoor and outdoor installation
Built-in convective fans for temperature control
Product Specifications
Phase
three
certification
ce, iso9001, tuv/g59
type
dc/ac inverters
circuit topologies
full-bridge type
max. dc voltage [v]
1000
min. dc voltage[v]
180v
power factor,adjustable(cosφ)
0.8 leading~0.8 lagging
max. efficiency
98.8%
specification
700*530*260 (mm)
nature of source flow
active inverter
output power
33000w
power source
solar power
nature of wave string
sine wave inverter
mppt voltage range [v]
180-900
number of mppt
3
total harmonic distortion (thdi)
< 3% (at nominal power)
mppt accuracy
>99.5%
Product Details
include IP65 protection and convective fans for durability. Backed by certifications and boasting high efficiency, it's an ideal choice for solar grid-tied systems.
