like IP65 protection and aluminum case design ensure reliability. With integrated communication interfaces and remote monitoring capabilities, it provides flexibility and control over energy management.
Integrated RS232/Wi-Fi interfaces for communication
Transformerless design for convenient installation
IP65 protection for durability
Aluminum case design for heat dissipation
Product Specifications
Product type
inverter
phase
single
certification
saa, ce, iso9001
type
dc/ac inverters
circuit topologies
full-bridge type
mppt voltage range [v]
90~550
number of dc input/mppt
2/2
battery type
lead-acid battery/lithium battery
max efficiency
97.60%
peak-to-trough period setting
integrated
power source
solar power
nature of wave string
sine wave inverter
min input voltage [v]
80
rated input voltage/voltage range [v]
48v
total harmonic distortion of current
<3%
mppt efficiency
>99.5%
communication mode
rs232 & 2*rs485; wi-fi / gprs / ethernet
Product Details
like IP65 protection and aluminum case design ensure reliability. With integrated communication interfaces and remote monitoring capabilities, it provides flexibility and control over energy management.
