Sanwa CL3000 Clamp Sensor In Pakistan Rs 27,148/-. The Sanwa CL3000 Clamp Sensor is a professional-grade AC clamp sensor designed for high-current measurement applications up to 3000A AC. Its compact design and wide jaw opening make it ideal for use in tight spaces and on large conductors in industrial environments. Built for reliability and safety, the CL3000 provides accurate current readings when connected to compatible measuring instruments, such as oscilloscopes, multimeters, or recorders. Whether you’re monitoring power distribution systems, large motors, or industrial equipment, this clamp sensor offers dependable performance with a high level of precision.
Compatible with multimeters, recorders, and oscilloscopes
Ideal for industrial and utility applications
Output voltage proportional to current for easy reading
Safety-compliant design with insulated jaws
Wide jaw opening suitable for large-diameter cables
Product Specifications
Type
clamp sensor
measurement range
30a / 300a / 3000a ac
accuracy
±(1.5%rdg + 5dgt) at 50/60hz
clamp jaw opening
max. 55mm diameter
dimensions
approx. 160 × 90 × 40 mm
frequency range
40hz – 1khz
operating temperature
0°c to 40°c
output sensitivity
1mv/a (at 3000a range)
output type
voltage output via banana plugs
power supply
no external power required
safety rating
iec61010-1 cat iii 600v
weight
approx. 350g
