Sanwa RD700 Multimeter Price In Pakistan Rs 33,000/-. The Sanwa RD700 is a reliable and easy-to-use True RMS digital multimeter designed for professionals and advanced users who need precision in a compact form. Equipped with a 6000-count backlit LCD, it delivers accurate AC/DC voltage and current measurements, along with resistance, frequency, capacitance, diode, and continuity testing. This meter features both auto and manual range selection, ensuring flexibility in various testing scenarios. With enhanced safety ratings (CAT IV 600V / CAT III 1000V), the RD700 is ideal for use in industrial, commercial, and field applications. It is compact, rugged, and built to perform reliably even under demanding conditions.
6000-count large LCD with backlight for easy viewing
Auto and manual range options for user flexibility
Compact and portable form factor
Data hold, relative value, and max/min functions
Diode test and continuity buzzer for quick circuit checks
High safety standard: CAT IV 600V / CAT III 1000V
Rugged design ideal for both lab and field use
Wide range of functions: voltage, current, resistance, frequency, capacitance, temperature
Product Specifications
Type
digital multimeter
display
6000-count lcd with backlight
ac current (true rms)
600µa / 6000µa / 60ma / 600ma / 6a / 10a
ac voltage (true rms)
6v / 60v / 600v / 1000v
capacitance
up to 100µf
data hold / max-min / relative measurement
yes
dc current
600µa / 6000µa / 60ma / 600ma / 6a / 10a
dc voltage
600mv / 6v / 60v / 600v / 1000v
dimensions
approx. 180 × 85 × 50 mm
diode / continuity test
yes (with audible buzzer)
frequency
10hz to 10mhz
input protection
yes (fuse and overload protection)
power supply
9v battery
range selection
auto and manual
resistance
up to 60mo
safety rating
cat iv 600v / cat iii 1000v
temperature
-50°c to +1000°c (k-type thermocouple supported)
weight
approx. 400g
Product Details
Sanwa RD700 Multimeter Price In Pakistan Rs 33,000/-. The Sanwa RD700 is a reliable and easy-to-use True RMS digital multimeter designed for professionals and advanced users who need precision in a compact form. Equipped with a 6000-count backlit LCD, it delivers accurate AC/DC voltage and current measurements, along with resistance, frequency, capacitance, diode, and continuity testing. This meter features both auto and manual range selection, ensuring flexibility in various testing scenarios. With enhanced safety ratings (CAT IV 600V / CAT III 1000V), the RD700 is ideal for use in industrial, commercial, and field applications. It is compact, rugged, and built to perform reliably even under demanding conditions.
