Range
|
easypact
product name
|
|
utilization category
|
category a
|
|
breaking capacity [icu]
|
25 ka icu at 380/415 v ac 50/60 hz conforming to iec 60947-2
|
|
trip unit name
|
tm-d
|
Schneider CVS100B 3P MCCB Breaker price in Pakistan is Rs 21,000/-.
EasyPact CVS100B is a 3-pole 3d fixed circuit breaker with a high level of performance and cost-saving functionality. It is an optimal choice for small and medium-sized building protection applications. The breaking capacity (Icu) is 25kA rms at 415VAC 50/60Hz. The operational voltage is 440VAC 50/60Hz. This product embeds a 16A, 25A, 32A, 40A, 50A, 63A, 80A, 100A rating thermal-magnetic trip unit (TMD). TMD trip unit provides adjustable thermal overload protection and fixed magnetic protection. This 3-pole version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. EasyPact CVS100B is compliant with international standards (IEC 60947, CCC, EAC). It can be installed in class II insulation switchboards as it is a class II front-face device (IEC 60664-1).
