TeSys D contactor, 4 poles (4NO), for non-inductive load applications up to 25A/440V AC-1. It provides a 220V 50/60Hz AC coil, 1NO+1NC built-in auxiliary contacts (NC mirror certified), connection by screw clamp terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).
power circuit; <= 690 v ac 25...400 hz / power circuit; <= 300 v dc
rated operational current [ie]
25
control circuit voltage [uc]
220 v ac 50/60 hz
compatibility code
lc1d
pole contact composition
4 no
contact compatibility
m6
protective cover
with
conventional free air thermal current [ith]
25 a (at 60 °c) for the power circuit / 10 a (at 60 °c) for the signalling circuit
rated breaking capacity
250 a at 440 v for power circuit conforming to iec 60947
average impedance
2.5 mohm - ith 25 a 50 hz for power circuit
overvoltage category
iii
pollution degree
3
mechanical durability
15 mcycles
control circuit type
ac at 50/60 hz
operating time
4...19 ms opening / 12...22 ms closing
maximum operating rate
3600 cyc/h 60 °c
auxiliary contact composition
1 no + 1 nc
signalling circuit frequency
25...400 hz
minimum switching voltage
17 v for signalling circuit
minimum switching current
5 ma for signalling circuit
insulation resistance
> 10 mohm for signalling circuit
mounting support
plate / rail
operating altitude
0...3000 m
fire resistance
850 °c conforming to iec 60695-2-1
flame retardance
v1 conforming to ul 94
Product Details
TeSys D contactor, 4 poles (4NO), for non-inductive load applications up to 25A/440V AC-1. It provides a 220V 50/60Hz AC coil, 1NO+1NC built-in auxiliary contacts (NC mirror certified), connection by screw clamp terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).
