24...575 v ac 40...400 hz with lx1/lx9 coil / 24...460 v dc with lx4 coil / 100...250 v ac 50/60 hz with lxe coil / 100...380 v dc with lxe coil
compatibility code
lc1f
pole contact composition
4 no
conventional free air thermal current [ith]
250 a (at 40 °c)
rated breaking capacity
1200 a conforming to iec 60947-4-1
average impedance
0.35 mohm - ith 250 a 50 hz
overvoltage category
iii
operating time
35 ms closing for with lx1/lx9 coil / 130 ms opening for with lx1/lx9 coil / 30...40 ms closing for with lx4 coil / 30...50 ms opening for with lx4 coil / 40...80 ms closing for with lxe coil / 6...54 ms opening for with lxe coil
