Schneider NS1250N 3P 1250A Breaker price in Pakistan is Rs 480,000/-.
This circuit breaker is part of the new generation of ComPacT NS630bN to NS3200 range. ComPacT NS new generation keeps the same performance and comes with a new transparent front cover for auxiliaries visibility and a new toggle with ergonomic touch and optional LED trip status. It is possible to add as an option the new wireless auxiliary contact OF/SD in the ZigBee communication protocol. This ComPacT NS1250N is a complete 3 poles circuit breaker designed to optimize space and breaking capacity. It is a fixed circuit breaker manually operated. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 50kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. The circuit breaker can be manually operated with ON, OFF, or "push to trip" buttons. This product embeds an electronic Micr...
[ics] rated service short-circuit breaking capacity
50 ka at 220/240 v ac 50/60 hz conforming to iec 60947-2 / 50 ka at 380/415 v ac 50/60 hz conforming to iec 60947-2 / 50 ka at 440 v ac 50/60 hz conforming to iec 60947-2 / 40 ka at 500/525 v ac 50/60 hz conforming to iec 60947-2 / 30 ka at 660/690 v ac 50/60 hz conforming to iec 60947-2
[icw] rated short-time withstand current
19.2 ka 1 s conforming to iec 60947-2
mechanical durability
10000 cycles
electrical durability
2000 cycles at 690 v in / 3000 cycles at 690 v in/2 / 4000 cycles at 440 v in / 5000 cycles at 440 v in/2
weight
14 kg
standards
en/iec 60947-2
product certifications
iecee cb scheme
pollution degree
3 conforming to iec 60947
ip degree of protection
ip40 conforming to iec 60529
1k degree of protection
ik07 conforming to en 50102
ambient air temperature for operation
-25...70 c
ambient air temperature for storage
-50...85 c
relative humidity
0...95 %
operating altitude
0...2000 m without derating / 2000 m...5000 m with derating
Product Details
Schneider NS1250N 3P 1250A Breaker price in Pakistan is Rs 480,000/-.
This circuit breaker is part of the new generation of ComPacT NS630bN to NS3200 range. ComPacT NS new generation keeps the same performance and comes with a new transparent front cover for auxiliaries visibility and a new toggle with ergonomic touch and optional LED trip status. It is possible to add as an option the new wireless auxiliary contact OF/SD in the ZigBee communication protocol. This ComPacT NS1250N is a complete 3 poles circuit breaker designed to optimize space and breaking capacity. It is a fixed circuit breaker manually operated. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 50kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. The circuit breaker can be manually operated with ON, OFF, or "push to trip" buttons. This product embeds an electronic MicroLogic 2.0 control unit, with a 1250A rating. MicroLogic 2.0 control unit provides adjustable long-time and instantaneous protections (ANSI codes 49/50). This product comes with a variety of optional functions and accessories. The dimensions are 327mm (Heigh) x 210mm (Width) x 147mm (Depth). It is compliant with IEC 60947-1 and IEC60947-2 international standards. ComPacT NS new generation is part of Schneider Electric EcoStruxure Power architecture. ComPacT NS new generation is more sustainable with green packaging and green partnerships.
