Schneider NSX160F 4P MCCB Breaker price in Pakistan is Rs 70,000/-.
This ComPacT NSX160F is a complete 4P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 36kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 125A, 160A rating thermal-magnetic trip unit (TMD). TMD trip unit provides adjustable thermal overload protection and fixed magnetic protection. This 4-pole version (140mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC, and marine specifications. ComPacT NSX160F is part of Schneider Electric EcoStruxure Power architecture.
36 ka icu at 380/415 v ac 50/60 hz conforming to iec 60947-2
performance level
f36ka415vac
trip unit name
tm-d
trip unit technology
thermal-magnetic
trip unit protection functions
li
control type
toggle
circuit breaker mounting mode
fixed
[ui] rated insulation voltage
800 v ac 50/60 hz
[uimpj rated impulse withstand voltage
8 kv
mechanical durability
40000 cycles
electrical durability
40000 cycles at 440 v in/2 / 20000 cycles at 440 v in / 15000 cycles at 690 v in/2 / 7500 cycles at 690 v in
net weight
2.6 kg
standards
en/iec 60947
product certifications
ccc, eac, marine
overvoltage category
class ii
electrical shock protection class
class ii
pollution degree
3 conforming to iec 60664-1
ip degree of protection
ip40 conforming to iec 60529
1k degree of protection
ik07 conforming to iec 62262
ambient air temperature for operation
- 25...70 c
ambient air temperature for storage
-50...85 c
relative humidity
0...95 0/0
operating altitude
0.-.2000 m without derating / 2000 m...5000 m with derating
Product Details
Schneider NSX160F 4P MCCB Breaker price in Pakistan is Rs 70,000/-.
This ComPacT NSX160F is a complete 4P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 36kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 125A, 160A rating thermal-magnetic trip unit (TMD). TMD trip unit provides adjustable thermal overload protection and fixed magnetic protection. This 4-pole version (140mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC, and marine specifications. ComPacT NSX160F is part of Schneider Electric EcoStruxure Power architecture.
