Range
|
compact new generation
|
|
product name
|
compact nsx new generation
|
|
product or component type
|
circuit breaker
|
|
device application
|
distribution
|
NSX250F 4 Pole Molded Case Circuit Breakers 200A, 250A This ComPacT NSX250F is a complete 4P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 36kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 200A, 250A rating thermal-magnetic trip unit (TMD). TMD trip unit provides adjustable thermal overload protection and fixed magnetic protection. This 4-pole version (140mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC, and marine specifications. ComPacT NSX250F is part of Schneider Electric EcoStruxure Power architecture.
