SMC VXS2230S-02 2 Ports Solenoid Valve Price in Pakistan is Rs.56,520/-. The SMC VXS2230S-02 2-Port Solenoid Valve is a high-performance, compact valve engineered for steam and high-temperature applications. Built to withstand temperatures up to 183°C, it ensures reliable operation and long service life in demanding industrial environments. Featuring a robust construction with aluminum, brass (C37), stainless steel, and premium sealing materials (NBR, FKM, EPDM), this valve offers exceptional durability and resistance to corrosion. Its IP65-rated enclosure provides dust-tight and water-jet-proof protection, making it suitable for harsh working conditions. The VXS2230S-02 is a pilot-operated, zero differential pressure diaphragm valve that delivers efficient, leak-free performance for air, water, and steam systems used in industrial automation and process control.
Designed specifically for steam and high-temperature use up to 183°C
Compact 2-port solenoid valve for efficient control
Compatible with air, water, and steam applications
Constructed from aluminum, brass, and stainless steel for enhanced durability
Ensures zero internal leakage under pressure
Ideal for industrial steam systems and automation processes
IP65-rated enclosure ensures protection from dust and water jets
Supports multiple voltage options for versatile use
Unrestricted mounting position for flexible installation
Zero differential pressure, pilot-operated diaphragm design
Product Specifications
Type
solenoid valve
ambient temperature
up to 183°c
atmosphere
suitable for non-corrosive, non-explosive environments
body material
aluminum, resin, brass (c37), stainless steel
enclosure
dust-tight, water-jet-proof (equivalent to ip65)
fluid temperature
1 to 60°c (standard), suitable for high-temperature steam
fluid type
air, water, steam
leakage
0 cm³/min (with water pressure)
mounting position
unrestricted
number of ports
2 port, normally closed (nc)
port size
1/4 inch
rated voltage
dc 24v (12v optional), ac 100v, 110v, 200v, 230v (other options available)
seal material
nbr, fkm, epdm
valve construction
zero differential pressure type, pilot-operated diaphragm
withstand pressure
0–145 psi / 0–1.0 mpa
Product Details
SMC VXS2230S-02 2 Ports Solenoid Valve Price in Pakistan is Rs.56,520/-. The SMC VXS2230S-02 2-Port Solenoid Valve is a high-performance, compact valve engineered for steam and high-temperature applications. Built to withstand temperatures up to 183°C, it ensures reliable operation and long service life in demanding industrial environments. Featuring a robust construction with aluminum, brass (C37), stainless steel, and premium sealing materials (NBR, FKM, EPDM), this valve offers exceptional durability and resistance to corrosion. Its IP65-rated enclosure provides dust-tight and water-jet-proof protection, making it suitable for harsh working conditions. The VXS2230S-02 is a pilot-operated, zero differential pressure diaphragm valve that delivers efficient, leak-free performance for air, water, and steam systems used in industrial automation and process control.
