SMC VXZ262K 2 Ports Solenoid Valve Price in Pakistan is Rs.145,800/-. The SMC VXP262K 2-Port Solenoid Valve is a compact, durable, and high-precision valve engineered for efficient control of air and water in industrial and automation systems. Designed with a robust aluminum, brass (C37), and stainless steel body, it ensures long-lasting performance under demanding conditions. Its IP65-rated enclosure makes it resistant to dust and water jets, ensuring reliability even in harsh environments. The valve operates on a zero differential pressure, pilot-operated diaphragm mechanism, providing stable and leak-free operation. Compatible with a range of AC and DC voltage options and a 1-inch port size, the VXP262K is ideal for fluid control systems requiring dependable, maintenance-free performance.
Compact 2-port solenoid valve for air and water applications
1-inch port size with unrestricted mounting position
Ideal for industrial fluid and pneumatic systems
IP65-rated dust-tight and water-jet-proof housing
Multiple voltage options (AC & DC) for flexible operation
Operates within –20°C to 60°C temperature range
Rugged construction using aluminum, brass, and stainless steel
Sealing materials include NBR, FKM, and EPDM for durability
Zero differential pressure, pilot-operated diaphragm design
Zero internal leakage under pressure
Product Specifications
Type
solenoid valve
ambient temperature
–20 to 60°c
atmosphere
suitable for non-corrosive, non-explosive environments
body material
aluminum, resin, brass (c37), stainless steel
enclosure
dust-tight, water-jet-proof (ip65 equivalent)
fluid temperature
1 to 60°c (no freezing)
fluid type
air, water, pure water (excluding waste or agricultural water)
leakage
0 cm³/min (with water pressure)
mounting position
unrestricted
number of ports
2 port, nc
port size
1 inch
rated voltage
dc 24v (12v optional), ac 100v, 110v, 200v, 230v (other voltages optional)
seal material
nbr, fkm, epdm
valve construction
zero differential pressure type pilot-operated diaphragm
withstand pressure
0–140 psi / 0–1.0 mpa
Product Details
SMC VXZ262K 2 Ports Solenoid Valve Price in Pakistan is Rs.145,800/-. The SMC VXP262K 2-Port Solenoid Valve is a compact, durable, and high-precision valve engineered for efficient control of air and water in industrial and automation systems. Designed with a robust aluminum, brass (C37), and stainless steel body, it ensures long-lasting performance under demanding conditions. Its IP65-rated enclosure makes it resistant to dust and water jets, ensuring reliability even in harsh environments. The valve operates on a zero differential pressure, pilot-operated diaphragm mechanism, providing stable and leak-free operation. Compatible with a range of AC and DC voltage options and a 1-inch port size, the VXP262K is ideal for fluid control systems requiring dependable, maintenance-free performance.
